NX and DX Series Transmitter Setup
1. Power ON your transmitter, click on scroll wheel, roll to System Setup, and click the scroll wheel. Select YES.
2. Go to Model Select and choose <Add New Model> at the bottom of the list. The system asks if you want to create
a new model, select Create.
3. Set Model Type: Select Helicopter Model Type by choosing the Helicopter. The system asks you to con rm model
type, data will be reset. Select YES.
4. Scroll down and select Model Name: Input a name for your model le Scroll up to BACK, and press the scroll wheel
to return to System Setup.
5. Scroll down and select F-Mode Setup. Set to: Switch 1: Switch B Hold Switch: Switch H
Scroll up to LIST, and press the scroll wheel to return to System Setup.
6. Scroll down and select Channel Assign. Scroll down on the Channel Input Con g screen, and set Ch 5 Gear to
F-Mode. Scroll down to Ch/Prt (Bold), Aux 5 and select B as the input.
7. Select <Main Screen>. Click the scroll wheel to enter the Function List.
8. Scroll down to Rates and Expo, and press the scroll wheel. Scroll down to Channel and select Aileron.
Set Switch: Switch F
Move Switch F to the O position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 1 position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 2 position > Set Low Rate %: 75 / 75; Expo %: 35 / 35
9. Scroll up to Channel and select Elevator. Set Switch: Switch F
Move Switch F to the O position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 1 position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 2 position > Set Low Rate %: 75 / 75; Expo %: 35 / 35
10. Scroll up to Channel and select Rudder. Set Switch: Switch F
Move Switch F to the O position > Set High Rate %: 100 / 100; Expo %: 45 / 45
Move Switch F to the 1 position > Set High Rate %: 100 / 100; Expo %: 45 / 45
Move Switch F to the 2 position > Set Low Rate %: 75 / 75; Expo %: 45 / 45
11. Scroll up to LIST, and press the scroll wheel to return to the Function List.
12. Scroll down to Throttle Curve, and press the scroll wheel.
Scroll to the N box for curve selection, and press the scroll wheel to select the Normal curve.
Set the Curve Values to:
1
2
0
65
13. Scroll to the #1 box for curve selection and press the scroll wheel to select the Stunt #1 curve.
Set the Curve Values to:
1
2
80
80
14. Scroll to the #2 box for curve selection, and press the scroll wheel to select the Stunt #2 curve.
Set the Curve Values to:
1
2
100
100
15. Scroll to the H box for curve selection, and press the scroll wheel to select the Hold curve.
Set the Curve Values to:
1
2
0
0
16. Scroll up to LIST, and press the scroll wheel to return to the Function List.
17. Scroll down to Pitch curve, and press the scroll wheel. Scroll to the N box for curve selection, and press the scroll
wheel to select the Normal curve. Set the Curve Values to:
1
2
25
37
18. Scroll to the #1 box for curve selection and press the scroll wheel to select the Stunt #1 curve.
Set the Curve Values to:
1
2
0
25
EN
www.modellmarkt24.ch
3
4
5
65
65
65
3
4
5
80
80
80
3
4
5
100
100
100
3
4
5
0
0
0
3
4
5
50
75
100
3
4
5
50
75
100
