Smart Throttle (BNF Only)
Spektrum ESCs feature a telemetry function called Smart
Throttle. Smart Throttle technology combines the throttle
signal with telemetry data from the ESC on a single, three
wire servo connector.
Smart Throttle ESCs can send current, voltage, ESC temp,
and mAh consumed. They can also exchange battery data
from compatible Spektrum Smart batteries. Smart Throttle
telemetry data displays on your transmitter like any other
telemetry sensor.
For Smart Throttle to function you must have a Smart
Throttle ESC paired with a Smart Throttle telemetry
receiver and a Spektrum DSMX transmitter with telemetry.
Check your receiver and ESC manual for more information
about Smart technology compatibility. To employ Smart
features, you may have to update your transmitter.
Visit www.spektrumrc.com to register and update your
transmitter.
Low Voltage Cuto (LVC)
The ESC will continuously lower power to the motor until
complete shutdown when the battery reaches 9V under
load. This helps prevent over-discharge of the Li-Po battery.
Land immediately when the ESC activates LVC. Continuing
to y after LVC can damage the battery, cause a crash or
both. Crash damage and batteries damaged due to over-
discharge are not covered under warranty.
Transmitter and Receiver Binding
This product requires an approved Spektrum DSM2
®
Visit www.bindnfly.com for a complete list of approved transmitters.
General Binding Procedure
1. Refer the Transmitter Setup Table to correctly set up your transmitter.
2. Lower the throttle stick to the lowest position. Set all trims to the center position.
3. Power off the transmitter and move all switches to the 0 position.
4. Install the bind plug in the receiver BIND/PROG port.
5. Connect the ight battery to the ESC.
6. Put the transmitter into bind mode while powering on the transmitter. Flip the model upside down and hold for 15s.
7. Release the bind button/switch after 2–3 seconds. The helicopter is bound when the LED on the receiver turns solid.
8. Disconnect the ight battery and power the transmitter off.
EN
www.modellmarkt24.ch
To activate Smart Telemetry:
1. Keep the vehicle powered ON after binding the trans-
mitter to the receiver.
2. Scroll to the Telemetry screen.
3. Scroll to Settings.
4. Select Auto Con g.
To activate speed infomation using Smart Telemetry:
1. After the initial Smart telemetry con guration, keep the
vehicle powered ON.
2. Scroll to the Telemetry screen.
3. Scroll to Smart ESC and double click.
4. Scroll to NEXT.
5. Enter the values for the motor magnetic pole count
(14-pole) and the gear ratio (10.77).
When the radio is ON and connected to a receiver sending
Smart Data, the Smart Logo appears near the battery logo
on the home page. A signal bar appears in the screen's
information bar along the top of the screen. Scroll past
the servo monitor to the Smart screen. Select either ESC,
battery or both to suit your preference.
Repeatedly ying the helicopter until LVC activates will
damage the helicopter battery.
Disconnect and remove the Li-Po battery from the aircraft
after use to prevent trickle discharge. During storage, make
sure the battery charge does not fall below 3V per cell.
/DSMX
compatible transmitter.
®
®
