RF Emissions Group 1
CISPR 11
RF Emissions Group 2
CISPR 11
RF Emissions Class A or B
CISPR 11
Harmonics Class A, B, C, D or N/A
IEC 61000-3-2
Flicker Complies or N/A
IEC 61000-3-3
RF Emissions Complies
CISPR 14-1
RF Emissions Complies
CISPR 15
10.5.
Immunity Test Summary – For All Equipment and Systems
The device is intended for use in the electromagnetic environment specified below. The customer or user of the device should ensure that it
is used in such an environment.
Immunity Test IEC 60601 Test Level
ESD ±6 kV Contact
EN/IEC 61000-4-2 ±8 kV Air
EFT ±2 kV Mains
EN/IEC 61000-4-4 ±1 kV I/Os
Surge ±1 kV Differential
EN/IEC 61000-4-5 ±2 kV Common
Voltage Dips/ Dropout >95 % Dip for 0.5 Cycle
EN/IEC 61000-4-11 60 % Dip for 5 Cycles
30 % Dip for 25 Cycles
>95 % Dip for 5
Seconds
Power Frequency 3 A/m
50/60 Hz
Magnetic Field
EN/IEC 61000-4-8
10.6.
Guidance and Manufacture's Declaration – Immunity– For Non-Life-Supporting Equipment
Immunity Test IEC 60601 Test
Level
Conducted RF 3 Vrms
IEC 61000- 4-6 150 kHz to 80 MHz
Radiated RF 3 V/m
IEC 61000- 4-3 80 MHz to 2.5 GHz
10.7.

Table: Recommended Separation Distances

The device is intended for use in the electromagnetic environment in which radiated disturbances are controlled. The customer or user of the
device can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF Communications
Equipment and the device as recommended below, according to the maximum output power of the communications equipment.
Below is the table of recommended separation distances between portable and mobile RF communications equipment and the device and
systems that are not life-supporting.
Max Output Power
(watts)
0.01
0.1
1
10
100
RSR-000524-000 (1)
The CTX uses RF energy only for its internal function. Therefore, its RF emissions are
very low and are not likely to cause any interference in nearby electronic equipment.
The CTX must emit electromagnetic energy in order to perform its intended function.
Nearby electronic equipment may be affected.
A
A
Complies
The CTX is not suitable for interconnection with other equipment.
The CTX is not suitable for interconnection with other equipment.
Compliance
Level
As specified
As specified
As specified
As specified
As specified
Compliance Electromagnetic Environment – Guidance
Level
Portable and mobile communications equipment should be separated
from the CTX by no less than the distances calculated/listed below:
D=(3.5/V1)(Sqrt P)
D=(3.5/E1)(Sqrt P) 80 to 800 MHz
(V1)Vrms D=(7/E1)(Sqrt P) 800 MHz to 2.5 GHz
where P is the max power in watts and D is the recommended separation
distance in meters.
(E1)V/m Field strengths from fixed transmitters, as determined by an
electromagnetic site survey, should be less than the compliance levels (V1
and E1).
Interference may occur in the vicinity of equipment containing a
transmitter.
Separation (m)
150 kHz to 80 MHz
D=(3.5/V1)(Sqrt P)
0.1166
0.3689
1.1666
3.6893
11.666
User Manual – CTX
Electromagnetic Environment – Guidance
Floors should be wood, concrete or ceramic tile. If floors are synthetic,
the r/h should be at least 30 %.
Mains power quality should be that of a typical commercial or hospital
environment.
Mains power quality should be that of a typical commercial or hospital
environment.
Mains power quality should be that of a typical commercial or hospital
environment. If the user of the CTX requires continued operation
during power mains interruptions, it is recommended that the 35700
be powered from an uninterruptible power supply or battery.
Power frequency magnetic fields should be that of a typical
commercial or hospital environment.
Separation (m)
80 to 800 MHz
D=(3.5/E1)(Sqrt P)
0.1166
0.3689
1.1666
3.6893
11.666
Separation (m)
800 MHz to 2.5 GHz
D=(7/E1)(Sqrt P)
0.2333
0.7378
2.3333
7.3786
23.333
Page 21 of 25
