Name Settings
Basic illumination ON- hh:mm:ss
period (for basic illumi-
nation only: basic illumi-
nation > active and basic
illumination: basic illumi-
nation ON > time-limited)
Basic illumination is switched OFF after expiry of the ON period that is set here.
Disable
Scenario No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
This parameter is used for selecting whether the output can be disabled,
and which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value "0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value "1".
Behaviour on disabling no action
ON
OFF
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
no action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Behaviour on enabling Continue control
ON
OFF
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON or OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
10.4 Constant-lighting control
Name Settings
General parameters
Constant-lighting control Automatically ON and
mode
OFF
Automatically OFF only
regardless of move-
ment
This parameter is used for selecting whether constant-lighting control is
governed by presence and light level (automatically ON and OFF & only
automatically OFF) or whether it is only governed by light level irrespective of
movement.
Slave input inactive
ON
ON/OFF
This parameter defines whether the slave input expects an ON telegram or
an ON and OFF telegram.
Factory setting Name
00:15:00 Stay-ON time, constant-
lighting control
Stay-ON time is started if no presence is detected. This has the purpose of
preventing the output from switching OFF immediately if the room is vacated
for a short time and having to be switched back ON again when a person
returns to the room.
Stay-ON time can be set from 00:00:10 to 18:12:15.
Automatic starting value
Yes: the sensor automatically determines the starting value after artificial light
No
calibration.
No: the sensor always starts with the given starting value.
Starting value, dimming
level until first Teach
This parameter defines the ON level when constant-lighting control is started.
The value is adopted until artificial light calibration. The sensor then deter-
mines the starting value for directly reaching the light-level setting as accu-
rately as possible.
Starting value, dimming
level
This parameter defines the ON level when constant-lighting control is started.
no action
Send switching object
This parameter is used to select whether to send the ON and OFF switching
commands or whether to send only ON or only OFF.
Send behaviour at
dimming input
Process: if this parameter is set to process, the detector behaves as selected
Continue control
under the "light-level control for dim input" parameter.
Pass on: the detector is disabled and passes on the unchanged input value
at the output.
Light-level control for dim
input
Disable and dim: constant-lighting control is not disabled after receiving a
telegram via the dimming object. After receiving a telegram, a delay of
approx. 5 seconds elapses before the new light-level value is adopted as
the set value. This setting is recommended if only one output is used for
illuminating the room.
Do not disable and move setting: if a telegram is received via the dimming
object, light-level control is disabled and the addressed output dimmed. This
setting is recommended if room lighting consists of several lighting groups.
2nd output
Factory setting
This parameter can be used to activate a second output.
Automatically ON and
Offset, 2nd output
OFF
This parameter is used for selecting the offset value for second output that
must be added to or subtracted from the dimming level measured by the
light-level controller for the first output (depending on whether the second
output is further away from or closer to the window than output 1) to provide
a workplace below output 2 with a level of light that is roughly the same as
that provided at the light-level setting selected for output 1.
Light level
ON
Light-level setting
This parameter is used for selecting the setting for light level control.
Light-level sensor
This parameter is used for activating an input object for external light-level
measurement. This value is used instead of the light level measured internally.
- 38 -
KNX Application Description for Control Pro Series
Settings
hh:mm:ss
Yes
No
1 % ... 100 %
1 % ... 100 %
ON/OFF
ON
OFF
Process
Pass on
disable and dim
do not disable and al-
ter setting
inactive
active
-100 % ... 100 %
2 lux ... 1000 lux
Internal
External
Factory setting
00:05:00
Yes
80
80
ON/OFF
Pass on
inactive
500
Internal
