Name Settings
Weighting, light-level 1 % ... 100 %
sensor, external
This value defines the extent to which the external value is weighted.
Switching threshold ON 2 lux ... 1000 lux
This parameter is used to select the light level and detected presence from
which to switch the light output ON.
Switch OFF in relation to Yes
light level
No
Yes: despite presence being detected, the light output is switched OFF if light
level is sufficient.
No: the light output stays switched ON until stay-ON time elapses. Stay-ON
time is re-triggered if presence is detected.
Offset switching thresh- 10 lux ... 1000 lux
old OFF
This parameter is used to select the offset from which to switch the light
output OFF.
Basic illumination (only visible when light output = dimming level)
Basic illumination inactive
active
Setting to specify whether the basic illumination is to be activated.
Basic illumination ON for a limited time
in relation to light level
dim
always
If required, the output can either be set to provide basic illumination either for
a limited period at the end of the stay-ON time or always when the light level
falls below a threshold.
time-limited: at the end of stay-ON time, the output switches lighting to basic
illumination if the detector was configured in daytime mode or the light level
currently being measured is below the switch-ON threshold + switch-OFF
threshold offset.
depending on light level: when no presence is being identified by the detec-
tor, this does not result in the output being switched OFF but in the activation
of basic illumination if the level of light measured at this time by the sensor
is below the basic light-level threshold. It remains switched ON until either
presence is detected or the level of light measured significantly exceeds the
basic light-level threshold. The light-level measurement setting is used by the
"Light-Level Measurement ON" parameter.
dim: the sensor automatically dims lighting down to the point at which it
switches OFF.
always: basic illumination is always active when the output is not switched
ON.
Basic illumination dim- 1 % ... 100 %
ming level
This parameter is used for setting the dimming level at which basic illumina-
tion is switched ON.
Basic illumination thresh- 2 lux ... 1000 lux
old level
This parameter is used for setting the threshold at which basic illumination is
activated if the threshold is not met, and at which it is deactivated again if the
threshold is significantly exceeded. This takes place irrespective of whether
persons are present in the detection zone or not.
Basic illumination hh:mm:ss
ON period
Basic illumination is switched OFF after expiry of the ON period that is set
here.
The ON-period can be set from 00:00:10 to 18:12:15.
Day night parameters
Day/night switchover inactive
active
When day/night switchover is activated, the parameter setting can be
switched over via an input object.
Factory setting Name
100 % ON level in percent
(only for General para-
meters: Object light
output > dimming level)
500
This parameter is used to select which dimming level to send
for the ON state.
OFF level in percent
(only for General para-
Yes
meters: Object light
output > dimming level)
This parameter is used to select which dimming level to send
for the OFF state.
Switch ON scene
(only for General
100
parameters: Object light
output > scene)
This parameter is used to select which scene to send for the ON state.
Switch OFF scene
(only for General
parameters: Object light
output > scene)
inactive
This parameter is used to select which scene to send for the OFF state.
Daytime operation
for a limited time
Setting to define whether light output is to be switched irrespective of light
level.
Switching threshold ON
This parameter is used to select the light level and detected presence from
which to switch the light output ON.
Switch OFF in relation to
light level
This parameter is used to switch OFF the light output in relation to ambient
light level in spite of someone being present.
Offset switching thresh-
old OFF
This parameter is used to select the offset from which to switch the light
output OFF.
Light output stay-ON
time
Stay-ON time is started if no presence is detected. This has the purpose of
preventing the output from switching OFF immediately if the room is only
vacated for a short time and having to be switched back ON again when a
person returns to the room.
Stay-ON time can be set from 00:00:10 to 18:12:15.
10
Basic illumination
dimming level (for basic
illumination only: basic
illumination > active
50
and basic illumination:
basic illumination ON >
time-limited, in relation
to ambient light level and
always)
This parameter is used for setting the dimming level at which basic illumina-
tion is switched ON.
00:15:00
Basic illumination
threshold level (for basic
illumination only: basic
illumination > active
and basic illumination:
basic illumination ON >
time-limited, in relation
to ambient light level)
inactive
This parameter is used for setting the threshold at which basic illumination is
activated if the threshold is not met, and at which it is deactivated again if the
threshold is significantly exceeded. This takes place irrespective of whether
persons are present in the detection zone or not.
- 37 -
KNX Application Description for Control Pro Series
Settings
0 % ... 100 %
0 % ... 100 %
1 ... 64
1 ... 64
Yes
No
2 lux ... 1000 lux
Yes
No
10 lux ... 1000 lux
hh:mm:ss
1 % ... 100 %
2 lux ... 1000 lux
Factory setting
100 %
0 %
1
2
No
500
No
100
00:05:00
10
50
