9.8 Description of HVAC communication objects
Object Description
Switch This object is always available when HVAC output is
activated and bit output object is selected.
HVAC
This object must be linked with the presence input of
the room-temperature regulator used for switching
the room mode between "comfort mode" and "ener-
gy-saving mode". The group address linked with this
object is used for sending the HVAC status via bus to
the regulator, with it also being possible to request this
from the detector.
HVAC This object is always available when HVAC output is
activated and bit output object is selected.
mode
This object must be linked with the presence input of
the room-temperature regulator used for sending Auto,
Comfort, Stand-By, Economy or Building Protection
room mode to the regulator. The group address linked
with this object is used for sending the HVAC status
via bus to the regulator, with it also being possible to
request this from the detector.
HVAC This object is always available when HVAC output is
activated.
stay-ON time
The group address linked with this object is used for
receiving the stay-ON time for the HVAC output via
bus. Any value received outside the permissible range
is rejected. This object can also be used at any time for
requesting the current stay-ON time.
HVAC This object is always available when HVAC output is
activated.
Switch-ON delay
The group address linked with this object is used for
receiving the switch-ON delay for the HVAC output via
bus. Any value received outside the permissible range
is rejected. This object can also be used at any time for
requesting the current stay-ON time.
HVAC This object is only visible if the "Slave input" parameter
is not set to "inactive".
Slave input
The group address linked with this object is used for
receiving the presence status of the slave via the bus
and, if applicable, linked with the presence status of
further slaves as well as that of the sensor via a logical
OR function and evaluated as total presence
for HVAC control.
HVAC This object is always available when the HVAC output
is activated and if the "Disable output" parameter is not
Disable
set to "No".
The "Disable output" parameter is also used for select-
ing whether to perform disabling on receiving a value of
"1" or on receiving a value of "0".
HVAC This object is only visible if the "Disable output" param-
eter is not set to "No".
Disabling status
The group address linked with this object is used for
automatically sending the disabling status via bus after
any change, with it being possible to request the disa-
bling status at any time.
KNX Application Description for Control Pro Series
9.9 Description of photo-cell controller
communication objects
Object Description
Photo-cell controller This object is always available when photo-cell control-
output ler outputs are activated.
The group address linked with this object is sent to
the actuator via bus if the light level measured is below
the twilight threshold selected (output = "ON") or not
( output = "OFF"); photo-cell controller status can be
requested from the detector at any time.
Twilight threshold This object is always available when photo-cell control-
ler is activated.
The group address linked with this object is used for
receiving the switching threshold (in lux) for the light
output via bus; this threshold can be requested at any
time.
Disable This object is always available when the photo-cell
controller is activated and if the "Disable output" para-
photo-cell controller
meter is not set to "No".
The "Disable output" parameter is also used for select-
ing whether to perform disabling on receiving a value of
"1" or on receiving a value of "0".
Photo-cell controller This object is only visible if the "Disable output" para-
meter is not set to "No".
disable status
The group address linked with this object is used for
automatically sending the disabling status via bus after
any change, with it being possible to request the disa-
bling status at any time.
9.10 Description of light level
communication objects
Object Description
Light level measured This object is always available when light-level out-
put is activated.
The group address linked with this object is used
for sending the internal light level measured by the
detector via bus, with it also being possible to
request the light level from the detector.
9.11 Description of sabotage
communication objects
Object Description
Sabotage This object is always available when sabotage out-
put is activated.
An ON or OFF telegram is sent cyclically to the
group address linked to this object while the sensor
is not disconnected from the bus or if it is faulty.
9.12 Description of output 8-bit scene
communication object
Object Description
8-bit scene output This object is always available when User remote con-
trol is activated.
The output delivers the number of the activated scene
defined in the parameters.
