STEINEL Control Pro IR Quattro Bedienungsanleitung Seite 41

Name Settings
Behaviour on enabling Continue control
ON
OFF
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON and OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
10.6 Absence output
Name Settings
0 ... 10
Switch-ON delay
(in seconds)
No movement must be detected throughout the switch-ON delay period.
Only then will the output switch ON.
Stay-ON time hh:mm:ss
Stay-ON time is started if no absence is detected. This has the purpose of
preventing the output from switching OFF immediately if the room is only
vacated for a short time and having to be switched back ON again when a
person returns to the room.
Stay-ON time can be set from 00:00:01 to 18:12:15.
Send status cyclically Do not send status
cyclically
ON/OFF
ON
OFF
This parameter is used for selecting whether the output not only sends after
any change but also cyclically and, if so, for which status.
Do not send status cyclically: no status is sent cyclically.
ON/OFF: ON and OFF status is sent cyclically
ON: only ON status is sent cyclically.
OFF: only OFF status is sent cyclically.
Interval for sending cy- hh:mm:ss
clically
Time interval for sending at cyclical intervals.
Disable output No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
This parameter is used for selecting whether the output can be disabled, and
which telegram can be used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value
"0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value
"1".
Behaviour on disabling no action
ON
OFF
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
no action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Factory setting Name
Continue control
Behaviour on enabling
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON and OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
10.7 HVAC output
Factory setting
Name
1
Type output object
This parameter is used for selecting whether the output object is of type bit
or byte.
00:00:30
Modus ON
ON
This parameter is used for selecting which byte signal to send to the regulator
when someone is present.
Mode OFF
This parameter is used for selecting which byte signal to send to the regulator
when no one is present.
00:00:30
Switch-ON delay (pres-
ence governed only)
A movement must be detected throughout the switch-ON delay period. Only
No then will the output switch ON.
The maximum switch-ON delay is 18:12:15.
Stay-ON time
(governed by presence
only)
Stay-ON time is started if no presence is detected. This has the purpose of
preventing the output from switching OFF immediately if the room is only
vacated for a short time and having to be switched back ON again when a
person returns to the room.
Stay-ON time can be set from 00:00:10 to 18:12:15.
Slave input
This parameter defines whether the slave input expects an ON
no action
telegram or whether it expects an ON and OFF telegram.
- 41 -
KNX Application Description for Control Pro Series
Settings
Continue control
ON
OFF
Settings
Bit
Byte
Auto
Convenience
Standby
Economy
Building Protection
Auto
Convenience
Standby
Economy
Building Protection
hh:mm:ss
hh:mm:ss
inactive
ON
ON/OFF
Factory setting
Continue control
Factory setting
Bit
Auto
Standby
00:05:00
00:15:00
ON
