9.5 Description of constant-lighting control
communication objects
Object Description
Constant-lighting This object is always available when constant-lighting
control control is activated.
The group address linked with this object is used for
Light-level setting
receiving the constant lighting-level control setting (in lux)
via bus; this setting can be requested at any time.
Constant-lighting This object is always available when constant-lighting
control is activated.
control
The group address linked with this object is used for
Stay-ON time
receiving the stay-ON time for constant-lighting control
via bus. Any value received outside the permissible
range is rejected. This object can also be used at any
time for requesting the current stay-ON time.
Constant-lighting This object is always available when constant-lighting
control 1, switch control is activated.
Depending on the "Send switching object" parameter,
the group address linked with this object sends the
switching command via bus to the actuator, with it also
being possible to request the switching status from the
detector.
Constant-lighting This object is always available when constant-lighting
control is activated.
control
The group address linked with this object is used for
Dimming level 1
sending the dimming value via bus to the actuator, with
it also being possible to request this from the detector.
Constant-lighting This object is always available when constant-lighting
control is activated.
control
The group address linked with this object is used for
Dim output 1
sending the brighter / darker telegram that is set via the
input to the actuator via the bus.
Constant-lighting This object is always available when constant-lighting
control is activated.
control
switch input 1 If the "Constant-lighting control mode" parameter is
set to "Automatically ON and OFF" and a telegram is
received via this object, constant lighting control will
be disabled because the room user wishes to switch
constant-lighting control light ON or OFF permanently.
It remains disabled until either the "Disable constant-
lighting control" object delivers a telegram for enabling
or until the detector establishes that no person is left in
the room who re-enables and switches OFF constant-
lighting control.
If the "Constant-lighting control mode" parameter is set
to "Automatically OFF" and a telegram "1" is received via
this object, constant lighting control will be switched ON
for the stay-ON time selected. Any presence detected
in the activated state will re-trigger the stay-ON time. If a
"0" is received, constant-lighting control will switch OFF
without disabling.
Constant-lighting This object is always available when constant-lighting
control is activated.
control
dim input 1 If a telegram is received via this object, and depending
on the "Dim light-level control at input" parameter set-
ting, constant-lighting control is either disabled with the
relevant output being dimmed, or light-level control is
not disabled and the constant-lighting control setting is
increased or decreased accordingly, automatically re-
sulting in a lighter or darker dimming of the lighting. If the
detector establishes that nobody remains in the room,
the altered light-level setting is returned to its original val-
ue and constant-lighting control is switched OFF.
KNX Application Description for Control Pro Series
Object Description
Constant-lighting This object is always available when constant-lighting
control is activated.
control
input 1 If a telegram is received on the basis of this object, the
dimming level constant-lighting control is disabled and the associated
output dimmed accordingly. If the detector establishes
that there is no longer anyone in the room, disabling is
cancelled and the lighting is switched OFF.
Constant-lighting This object is always available when constant-lighting
control is activated.
control
Teach The group address linked with this object is used for
carrying out artificial light calibration with a "1" telegram.
Constant-lighting This object is only visible if the "2nd output" parameteris
control set to "active".
2, switch Depending on the "Send switching object" parameter,
the group address linked with this object sends the
switching command via bus to the actuator, with it also
being possible to request the switching status from the
detector.
Constant-lighting This object is only visible if the "2nd output" parameteris
control set to "active".
dimming level 2
The group address linked with this object is used for
sending the dimming value via bus to the actuator, with
it also being possible to request this from the detector.
Constant-lighting This object is only visible if the "2nd output" parameteris
set to "active".
control
dim output 2 The group address linked with this object is used for
sending the brighter / darker telegram that is set via the
input to the actuator via the bus.
Constant-lighting This object is only visible if the "2nd output" parameter is
set to "active".
control
switch input 2 If the "Constant-lighting control mode" parameter is
set to "Automatically ON and OFF" and a telegram is
received via this object, constant lighting control will be
disabled because the room user wishes to switch con-
stant-lighting control light ON or OFF permanently.
It remains disabled until either the "Disable constant-
lighting control" object delivers a telegram for enabling
or until the detector establishes that no person is left in
the room who re-enables and switches OFF constant-
lighting control.
If the "Constant-lighting control mode" parameter is set
to "Automatically OFF" and a telegram "1" is received via
this object, constant lighting control will be switched ON
for the stay-ON time selected. Any presence detected
in the activated state will re-trigger the stay-ON time. If a
"0" is received, constant-lighting control will switch OFF
without disabling.
Constant-lighting This object is only visible if the "2nd output" parameter is
set to "active".
control
dim input 2 If a telegram is received via this object, and depending
on the "Dim light-level control at input" parameter set-
ting, constant-lighting control is either disabled with the
relevant output being dimmed, or light-level control is
not disabled and the constant-lighting control setting
is increased or decreased accordingly, automatically
resulting in a lighter or darker dimming of the lighting.
If the detector establishes that nobody remains in the
room, the altered light-level setting is returned to its orig-
inal value and constant-lighting control is switched OFF.
