Object Object name
HVAC
78.
mode
HVAC
79.
stay-ON time
HVAC
80.
switch-ON delay
HVAC
81.
slave input
Disable
82.
HVAC
HVAC
83.
disabling status
Logic gate 1
84.
input 1
Logic gate 1
85.
input 2
Logic gate 1
86.
input 3
Logic gate 1
87.
input 4
Logic gate 1
88.
output
Logic gate 1
89.
output
Logic gate 1
90.
disable
Logic gate 1
91.
disable status
Logic gate 2
92.
input 1
Logic gate 2
93.
input 2
Logic gate 2
94.
input 3
Logic gate 2
95.
input 4
Logic gate 2
96.
output
Logic gate 2
97.
output
Logic gate 2
98.
disable
Logic gate 2
99.
disable status
Constant-lighting control
100.
light-level setting
Constant-lighting control,
101.
stay-ON time
Constant-lighting control 1,
102.
switch input
Constant-lighting control 1,
103.
dimming level
Dim constant-lighting con-
104.
trol output 1
Switch constant-lighting
105.
control input 1
Constant-lighting control
106.
input 1, dimming
Constant-lighting control
107.
input 1 dimming level
Function DPT Flag
0 ... 4 20,001 CRT
10 s ... 65535 s 7,005 CRWT
0 s ... 65535 s 7,005 CRWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CRT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CRT
0 ... 255 5,001 CRT
ON/OFF 1,001 CWT
ON/OFF 1,001 CRT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CRT
0 ... 255 5,001 CRT
ON/OFF 1,001 CWT
ON/OFF 1,001 CRT
2 ... 1000 lux 9,004 CRWT
10 s ... 65535 s 7,005 CRWT
ON/OFF 1,001 CRWT
0 % ... 100 % 5,001 CRT
brighter / darker 3,007 CRT
ON/OFF 1,001 CWT
brighter / darker 3,007 CWT
0 % ... 100 % 5,001 CWT
KNX Application Description for Control Pro Series
Object Object name
Teach constant-lighting
108.
control
Constant-lighting control,
109.
switch 2
Constant-lighting control,
110.
dimming level 2
Dim constant-lighting con-
111.
trol output 2
Switch constant-lighting
112.
control input 2
Dim constant-lighting con-
113.
trol input 2
Constant-lighting control
114.
input 2 dimming level
Constant-lighting control,
115.
slave input
Constant-lighting control
116.
external light level
Constant-lighting control
117. external light level
(DUAL light sensor only)
Constant-lighting control,
118.
night input
Disable constant-lighting
119.
control
Constant-lighting control
120.
disable status
9.2 Description of communication object
status
Object Description
Status This object is always available.
This object feeds back whether the sensor selected in
the Sensor selected parameter in the general settings
matches the sensor fitted. It they do match, the relevant
sensor type is returned; if the combination does not
match, a fault is returned and the sensor will not work.
Product and associated hex value:
Fault 0 × 00
IR Quattro 0 × 01
IR Quattro HD 0 × 02
HF 360 0 × 03
Dual HF 0 × 04
DualTech 0 × 05
US 360 0 × 06
Single US 0 × 07
Dual US 0 × 07
- 30 -
Function DPT Flag
ON/OFF 1,001 CWT
ON/OFF 1,001 CRWT
0 % ... 100 % 5,001 CRT
brighter / darker 3,007 CRT
ON/OFF 1,001 CWT
brighter / darker 3,007 CWT
0 % ... 100 % 5,001 CWT
ON/OFF 1,001 CWT
Lux 9,004 CWT
Lux 9,004 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CWT
ON/OFF 1,001 CRT
