9.3 Description of boost factor (HF & US sensors) and
sensitivity communication objects
Object Description
Boost factor This object is always available when an HF or US pres-
ence detector is selected.
This object is used for setting the boost factor for sensor
reach.
Sensitivity This object is always available. This object is used for
adjusting the sensitivity of the sensor in order to avoid
switching errors.
9.4 Description of communication objects
light output X (1..2)
Object Description
Light output X This object is always available when the light output is
activated.
Switching
Light output X is switched with this object.
The group address linked with this object is used for
sending the switching command via bus to the actuator,
with it also being possible to request the switching sta-
tus from the detector.
Light output X This object is always available when the light output is
activated.
Switch input
If the "Light output mode" parameter is set to "Automat-
ically ON and OFF" and a telegram is received via this
object, light output X will be disabled because the room
user wishes to switch the light output ON or OFF per-
manently. It remains disabled until either a telegram for
enabling is received via the "Disable light output X" ob-
ject or until the detector establishes that no person is left
in the room who re-enables light output X and switches
light output X OFF.
If the "Light output mode" parameter is set to "Automat-
ically OFF" and a telegram"1" is received via this object,
light output X will be switched ON for the stay-ON time
selected. Any presence detected in the activated state
will re-trigger the stay-ON time. If a "0" is received, light
output X will switch OFF without disabling.
Light output X This object is only visible if the "Object light output"
parameter is set to "Dimming level".
Dimming level
The group address linked with this object is used for
sending the dimming value via bus to the actuator, with
it also being possible to request this from the detector.
Light output X This object is only visible if the "Object light output"
parameter is set to "Dimming level".
Dim output
The group address linked with this object is used for
sending the brighter / darker telegram that is set via the
input to the actuator via the bus.
Light output X This object is only visible if the "Object light output"
parameter is set to "Dimming level".
Dim input
If a telegram is received via this object, light output X will
be disabled because the room user wishes to perma-
nently dim the light output to a different level. It remains
disabled until either a telegram for enabling is received
via the "Disable light output X" object or until the detec-
tor establishes that no person is left in the room who
re-enables light output X and switches light output X
OFF. On enabling, the light output X sends its set value
via the bus.
KNX Application Description for Control Pro Series
Object Description
Light output X This object is only visible if the "Object light output"
parameter is set to "Dimming level".
Input dimming level
If a telegram is received via this object, light output X will
be disabled because the room user wishes to perma-
nently dim the light output to a different level. It remains
disabled until either a telegram for enabling is received
via the "Disable light output X" object or until the detec-
tor establishes that no person is left in the room who
re-enables light output X and switches light output X
OFF. On enabling, the light output X sends its set value
via the bus.
Light output X This object is only visible if the "Object light output"
parameter is set to "Scene".
Scenario
The group address linked with this object is used for
sending the scene via bus to the actuator, with it also
being possible to request this from the detector.
Light output X This object is only visible if the "Slave input" parameter
is not set to "inactive".
Slave input
The group address linked with this object is used for re-
ceiving the presence status of the slave via the bus and,
if applicable, linked with the presence status of further
slaves as well as that of the sensor via a logical OR func-
tion and evaluated as total presence for light output X.
Light output X This object is always available when the light output is
activated.
Switching threshold
The group address linked with this object is used for re-
ceiving the switching threshold (in lux) for the light output
via bus; this threshold can be requested at any time.
Light output X This object is always available when the light output is
activated.
Stay-ON time
The group address linked with this object is used for
receiving the stay-ON time for the light output X via
bus. Any value received outside the permissible range
is rejected. This object can also be used at any time for
requesting the current stay-ON time.
Light output X This object is only visible if the "Light-level sensor ON"
parameter is set to "External".
External
The group address linked with this object is used for
receiving the light level measured by a light-level sensor
and for comparing it with the threshold.
Light output X This object is only visible if the "Day/night switchover"
parameter is not set to "inactive".
Night input
The group address linked with this object is used for
receiving switchover between day and night. Setting
a "0" activates the parameters for daytime operation.
Setting a "1" activates the parameters for night-time
operation.
Light output X This object is only visible if the "Disable output" para-
meter is not set to "No".
Disable
The "Disable output" parameter is also used for select-
ing whether to perform disabling on receiving a value of
"1" or on receiving a value of "0". When presence output
is disabled, the output sends no telegrams. Except
when manually overridden via the input objects.
Light output X This object is only visible if the "Disable output" para-
meter is not set to "No".
Disabling status
The group address linked with this object is used for
automatically sending the disabling status via bus after
any change, with it being possible to request the disa-
bling status at any time.
