Object Description
Constant-lighting This object is only visible if the "2nd output" parameter is
set to "active".
control
input 2 If a telegram is received on the basis of this object, the
dimming level constant-lighting control is disabled and the associated
output dimmed accordingly. If the detector establishes
that there is no longer anyone in the room, disabling is
cancelled and the lighting is switched OFF.
Constant-lighting This object is only visible if the "Slave input" parameter
is not set to "inactive".
control
slave input The group address linked with this object is used for re-
ceiving the presence status of the slave via the bus and,
if applicable, linked with the presence status of further
slaves as well as that of the sensor via a logical OR
function and evaluated as total presence for constant-
lighting control.
Constant-lighting This object is only visible if the "Light-level sensor"
parameter is set to "External".
control
external light level The group address linked with this object is used for
receiving the light level measured by a light-level sensor
and for comparing it with a selected setting.
Constant-lighting This object is only visible if the "Day/night switchover"
control parameter is not set to "inactive".
night input The group address linked with this object is used for
receiving switchover between day and night. Setting
a "0" activates the parameters for daytime operation.
Setting a "1" activates the parameters for night-time
operation.
Disable This object is only visible if the "Disable output" parame-
constant-lighting ter is not set to "No".
control
The "Disable output" parameter is also used for select-
ing whether to perform disabling on receiving a value of
"1" or on receiving a value of "0".
If the output is disabled, it can be manually overridden
via the input objects.
Constant-lighting This object is only visible if the "Disable output" parame-
control ter is not set to "No".
disable status The group address linked with this object is used for
automatically sending the disabling status via bus after
any change, with it being possible to request the disa-
bling status at any time.
9.6 Description of presence output
communication objects
Object Description
Presence output This object is always available when presence output
is activated.
Presence
The group address linked with this object is sent to
the actuator via bus, indicating whether presence of
persons have been detected (output = "ON") or not
( output = "OFF"); presence status can be requested
from the detector at any time.
Presence output This object is always available when presence output
stay-ON time is activated.
The group address linked with this object is used for
receiving the stay-ON time for the presence output via
bus. Any value received outside the permissible range
is rejected. This object can also be used at any time for
requesting the current stay-ON time.
KNX Application Description for Control Pro Series
Object Description
Presence output This object is always available when presence output
is activated.
switch-ON delay
The group address linked with this object is used for
receiving the switch-ON delay for the presence output
via bus. Any value received outside the permissible
range is rejected. This object can also be used at any
time for requesting the current stay-ON time.
Disable presence This object is only visible if the "Disable output" param-
eter is not set to "No".
output
The "Disable output" parameter is also used for select-
ing whether to perform disabling on receiving a value
of "1" or on receiving a value of "0". When presence
output is disabled, the output sends no telegrams.
Presence output This object is only visible if the "Disable output" param-
eter is not set to "No".
disable status
The group address linked with this object is used for
automatically sending the disabling status via bus after
any change, with it being possible to request the disa-
bling status at any time.
9.7 Description of absence output
communication objects
Object Description
Absence output This object is always available when the absence out-
absence put is activated.
The group address linked with this object is sent to
the actuator via bus, indicating whether absence of
persons have been detected (output = "ON") or not
( output = "OFF"); absence status can be requested
from the detector at any time.
Absence output This object is always available when the absence out-
stay-ON time put is activated.
The group address linked with this object is used for
receiving the stay-ON time for the absence output via
bus. Any value received outside the permissible range
is rejected. This object can also be used at any time for
requesting the current stay-ON time.
Absence output This object is always available when the absence out-
put is activated.
switch-ON delay
The group address linked with this object is used for
receiving the switch-ON delay for the absence output
via bus. Any value received outside the permissible
range is rejected. This object can also be used at any
time for requesting the current stay-ON time.
Disable absence This object is only visible if the "Disable output" param-
eter is not set to "No".
output
The "Disable output" parameter is also used for select-
ing whether to perform disabling on receiving a value
of "1" or on receiving a value of "0". When presence
output is disabled, the output sends no telegrams.
Absence output This object is only visible if the "Disable output" param-
eter is not set to "No".
disable status
The group address linked with this object is used for
automatically sending the disabling status via bus after
any change, with it being possible to request the disa-
bling status at any time.
