9.13 Description of logic gate X (1..2)
communication objects
Object Description
Logic gate X This object is always available when logic gate is acti-
vated.
Input 1
The group address linked with this object is used for
controlling the logical input of the logic gate. The inputs
can be linked in the way defined by the "Type of logic
operation" parameter.
Logic gate X This object is always available when at least one logic
gate is activated and if the "Number of inputs" parame-
Input 2
ter is greater than or equal to two inputs.
The group address linked with this object is used for
controlling the logical input of the logic gate. The inputs
can be linked in the way defined by the "Type of logic
operation" parameter.
Logic gate X This object is always available when at least one logic
gate is activated and if the "Number of inputs" parame-
Input 3
ter is greater than or equal to three inputs.
The group address linked with this object is used for
controlling the logical input of the logic gate. The inputs
can be linked in the way defined by the "Type of logic
operation" parameter.
Logic gate X This object is always available when at least one logic
gate is activated and if the "Number of inputs" parame-
Input 4
ter is greater than or equal to four inputs.
The group address linked with this object is used for
controlling the logical input of the logic gate. The inputs
can be linked in the way defined by the "Type of logic
operation" parameter.
Logic gate X This object is only visible if the "Logic gate" parameter
is set to "active" in the "General parameters" parameter
Output 1 bit
window and the "Logic gate X type output object" is
set to "ON/OFF".
The group address linked with this object is used for
sending the output state via bus to the actuator, with it
also being possible to request this from the detector.
Logic gate X This object is only visible if the "Logic gate" parameter
is set to "active" in the "General parameters" parameter
Output 1 byte
window and the "Logic gate X type output object" is
set to "Level".
The group address linked with this object is used for
sending the output value via bus to the actuator, with it
also being possible to request this from the detector.
Logic gate X This object is always available when logic gate is acti-
vated.
Disable
The "Disable output" parameter is also used for select-
ing whether to perform disabling on receiving a value of
"1" or on receiving a value of "0".
When presence output is disabled, the output sends
no telegrams.
Logic gate X This object is only visible if the "Disable output" param-
eter is not set to "No".
Disabling status
The group address linked with this object is used for
automatically sending the disabling status via bus after
any change, with it being possible to request the disa-
bling status at any time.
KNX Application Description for Control Pro Series
10. ETS parameters
Note on the colours in the parameter settings:
Parameters always available. All parameter-related colours are
reset from here on downwards.
Parameter only visible in relation to a setting of another
parameter. Settings and dependent parameters are marked
in the same colour.
Parameter only visible in relation to settings of two other
parameters. Settings and dependent parameters are marked
in the same colour.
10.1 General parameters
Name
Sensor selected
Please select the sensor used.
Number of light outputs
This parameter is used for setting how many light outputs are to be available.
Constant-lighting control inactive
active: the constant-lighting control output with the associated parameters is
additionally available.
inactive: the constant-lighting control output is not available.
Presence output
active: the presence output with the associated parameters is additionally
available.
inactive: the presence output is not available.
Absence output
active: the absence output with the associated parameters is additionally
available.
inactive: the absence output is not available.
HVAC output
active: the HVAC output with the associated parameters is additionally avail-
able.
inactive: the HVAC output is not available.
Photo-cell controller
output
active: the photo-cell controller output with the associated parameters is
additionally available.
inactive: the twilight output is not available.
Light level output
active: the light-level output with the associated parameters is additionally
available.
inactive: the light-level output is not available.
Sabotage
active: the sabotage output with the associated parameters is additionally
available.
inactive: the sabotage output is not available.
- 35 -
Settings Factory setting
IR Quattro DUAL HF
IR Quattro HD
HF 360
DUAL HF
DualTech
US 360
Single US
DUAL US
0 ... 4 1
inactive
active
inactive inactive
active
inactive inactive
active
inactive inactive
active
inactive inactive
active
inactive inactive
active
inactive inactive
active
