Name Settings
Disable output No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
This parameter is used for selecting whether the output can be disabled, and
which telegram can be used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value "0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value "1".
Behaviour on disabling no action
ON
OFF
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
no action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Continue control
Behaviour on enabling
ON
OFF
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON and OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
Slave input inactive
ON
ON/OFF
This parameter defines whether the slave input expects an ON telegram or
whether it expects an ON and OFF telegram.
10.8 Photo-cell controller output
Name Settings
Twilight threshold 2 lux ... 1000 lux
This parameter is used to select the light level from which to switch ON the
photo-cell controller output.
Disable output No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
This parameter is used for selecting whether the output can be disabled, and
which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value "0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value "1".
Factory setting Name
No Behaviour on disabling
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
no action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Behaviour on enabling
This parameter is used to select whether the output is to resume its activity
no action
after enabling or whether to switch the output ON and OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
Light-level sensor
(DUAL light sensor only)
Continue control
This parameter is used for selecting which light-level measurement to apply
for constant-lighting control.
Mixed light component
Diffuse
This parameter can be used for defining the component of diffusely meas-
ured light in the light level used for constant lighting control. The remaining
component is fed in via spot measurement.
ON
10.9 Light level output
Name
Send measured value
This parameter is used for selecting whether only to send the measurement
readings after any change or cyclically via bus.
Min. light-level change
Factory setting
This parameter is used to select which level the light level measured last sent
50 lux
must have changed by before the light level measured is to be sent again.
Send measured level
cyclically
No
Time interval for sending all measured light levels at cyclical intervals. The
cyclical sending mode can be set from 00:00:10 to 18:12:15.
10.10 Sabotage
Name
Interval for sending cy-
clically
Time interval for cyclically sending the sabotage telegram as heartbeat.
The cyclical sending mode can be set from 00:00:10 to 18:12:15.
Telegram
This parameter defines whether to send an ON telegram or OFF telegram
cyclically.
