10.11 Logic gates 1 ... 2 (all identical)
Name Settings
Logic gate OR; AND;
Exclusive OR
type of logic operation
This parameter defines the logic operation the gate performs.
Logic gate 1 ... 4
number of inputs
This parameter defines how many inputs the gate has.
ON/OFF
Logic gate
type of output object
Value
This parameter selects output type.
Logic gate switching ON; OFF
command for logical 0
This parameter is used to configure which switching command is sent for a
logical "0".
Logic gate switching ON; OFF
command for logical 1
This parameter is used to configure which switching command is sent for a
logical "1".
Logic gate 0 ... 255
value for logical 0
This parameter is used to configure which value is sent for a logical "0".
0 ... 255
Logic gate
Value at logic 1
This parameter is used to configure which value is sent for a logical "1".
Logic gate on changing logic;
Send behaviour, output on changing logic to 1;
on changing logic to 0;
This parameter is used for setting output sending behaviour.
Logic gate No
Disable
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
This parameter is used for selecting whether the output can be disabled,
and which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value "0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value "1".
Logic gate no action
ON
Behaviour on disabling
OFF
This parameter is used to select whether to switch the output
ON or OFF before disabling or whether to leave the output unchanged.
no action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Factory setting
OR
2
ON/OFF
OFF
ON
0
255
on changing logic;
No
no action
