Name Settings
Minimum dimming level 0.5 %; 1 %; 2 %; 3 %;
4 %; 5 %; 6 %; 7 %;
8 %; 9 %; 10 %
If the light-level controller measures a dimming level below the level selected
here, lighting remains dimmed at the minimum dimming level.
Basic illumination 1 % ... 100 %
dimming level (for basic
illumination only: basic
illumination > active
and basic illumination:
basic illumination ON >
time-limited, in relation
to ambient light level and
always)
This parameter is used for setting the dimming level at which basic illumina-
tion is switched ON.
Basic illumination hh:mm:ss
ON-period (for basic
illumination only: basic
illumination > active
and basic illumination:
basic illumination ON >
time-limited)
Basic illumination is switched OFF after expiry of the ON period that is set
here. Maximum ON time is 18:12:15.
Basic illumination 2 lux ... 1000 lux
threshold level (for basic
illumination only: basic
illumination > active
and basic illumination:
basic illumination ON >
time-limited, in relation
to ambient light level)
This parameter is used for setting the threshold at which basic illumination is
activated if the threshold is not met, and at which it is deactivated again if the
threshold is significantly exceeded. This takes place irrespective of
whether persons are present in the detection zone or not.
Disable
Disable output No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
This parameter is used for selecting whether the output can be disabled, and
which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value "0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value "1".
Behaviour on disabling no action
ON
OFF
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
no action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Factory setting Name
0.5 % Behaviour on enabling
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON and OFF first.
10
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
10.5 Presence output
Name
00:15:00
Switch-ON delay
(in seconds)
A movement must be detected throughout the switch-ON delay period. Only
then will the output switch ON.
Stay-ON time
Stay-ON time is started if no presence is detected. This has the purpose of
preventing the output from switching OFF immediately if the room is vacated
for a short time and having to be switched back ON again when a person
50
returns to the room.
Stay-ON time can be set from 00:00:00 to 18:12:15.
Send status cyclically
This parameter is used for selecting whether the output not only sends after
any change but also cyclically and, if so, for which status.
Do not send status cyclically: no status is sent cyclically.
ON/OFF: ON and OFF status is sent cyclically
ON: only ON status is sent cyclically.
OFF: only OFF status is sent cyclically.
No
Interval for sending
cyclically
Time interval for sending at cyclical intervals.
Disable output
This parameter is used for selecting whether the output can be disabled, and
which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
no action
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value "0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value "1".
Behaviour on disabling
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
no action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
- 40 -
KNX Application Description for Control Pro Series
Settings
Continue control
ON
OFF
Settings
0 s ... 10 s
hh:mm:ss
Do not send status
cyclically
ON/OFF
ON
OFF
hh:mm:ss
No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
no action
ON
OFF
Factory setting
Continue control
Factory setting
1
00:00:30
ON
00:00:30
No
no action
