Note: The EPAC generally gives you assistance
up to a maximum range of 70km.
The range depends on the driving conditions
and the assistance level.
A range of 100km is achievable with a fully
charged battery, minimal wind, constant speed,
well-paved roads, a maximum load of 75 kg and
an outside temperature of about 20°C.
Rechargeable battery and
rechargeable battery charger
WARNING
Risk of explosion!
If used improperly, there is a risk of the recharge-
able battery exploding.
• Keep the rechargeable battery away from ex-
cessive heat, prolonged exposure to sunlight,
and fire.
WARNING
Risk of injury!
• Improper use of the rechargeable battery can
lead to injuries.
• If you have not used the rechargeable battery
for longer than 30 days, recharge it fully.
• Recharge the rechargeable battery complete-
ly every 90 days since it may otherwise dis-
charge by itself and become permanently
damaged.
• If the rechargeable battery emits a strong
odour or gets hot, stop using it immediately.
• The rechargeable battery may only be
used with the rechargeable battery charger
supplied. The rechargeable battery charger is
not intended for use by persons (including chil-
dren) with limited physical, sensory, or mental
capabilities or by those lacking experience or
knowledge, unless they have been instructed
and supervised in the use of the device by a
person who is responsible for their safety.
• Children should be supervised to ensure
that they do not play with the rechargeable
battery charger.
• Cleaning and maintenance may not be car-
ried out by children.
• Inspect the plugs and connection cable
regularly. If the connection cable is damaged,
it must be replaced by the manufacturer, their
customer service department, or a qualified
person in order to avoid risks.
• Disconnect the rechargeable battery charger
from the power supply and let it cool down
before you clean, store, or transport it.
• Protect the electrical parts from humidity. Do
not immerse (e.g. the rechargeable battery)
in water or other liquids during cleaning, as
this may result in an electric shock. Do not
hold the rechargeable battery charger under
running water.
• The rechargeable battery must be in a
well-ventilated location during charging.
• Remove the rechargeable battery charger
from the product when the rechargeable
battery is fully charged.
Check the rechargeable battery charger
regularly for signs of damage. A damaged re-
chargeable battery charger must be repaired
before being used again.
• Do not use the rechargeable battery charger
if it has been exposed to vibrations or impacts
or if it has been dropped or damaged in some
other way.
• Never connect a damaged rechargeable
battery to the rechargeable battery charger.
Risk of electric shock!
• Never take the rechargeable battery charger
apart. Repairs must be performed by an
accredited customer service department.
Incorrect assembly can lead to fire or electric
shock.
• Never use the rechargeable battery charger
near explosive or flammable materials. There
is a risk of fire and explosion.
• Check the technical data before you connect
the rechargeable battery charger to the
power supply. Connect the rechargeable
battery charger only to a plug that matches
the technical data on the type plate. Risk of
electric shock!
• The rechargeable battery charger is intended
for use in indoor spaces only.
• Always use the rechargeable battery charger
as designed. The rechargeable battery charg-
er is intended for use only with the recharge-
able battery that is built into the product. Use
of any other kind can lead to fire or electric
shock. Make sure that the rechargeable
battery charger and the charge connection
have been properly connected and are not
impeded by foreign objects.
• Keep the charge connection clean and dry
and protect it from dirt and humidity.
• Do not place any objects on top of the re-
chargeable battery charger and do not cover
it up since this might lead to overheating.
• Do not position the rechargeable battery
charger near a heat source.
• Always place the charging cable so that no
one can trip over it, step on it, or damage it
in any other kind of way. In case of non-com-
pliance there is a risk of material damage or
injuries.
• Do not separate the rechargeable battery
charger from the power supply by pulling the
connection cable.
Always hold the power plug to disconnect the
power.
Rechargeable batteries may not be exposed
to any mechanical impacts. There is a risk that
the rechargeable battery will be damaged.
• The rechargeable battery may not be charged
unattended.
Charging the rechargeable
battery
With a saddle post with an integrated recharge-
able battery (14) the rechargeable battery is
built in and can be charged directly on the EPAC
or it can be removed for charging.
Note: The charging check light (2a) on the
rechargeable battery charger (2) comes on
during charging and lights up red. When charg-
ing is complete, the charging check light on the
rechargeable battery charger lights up green.
Be mindful of the following:
• IMPORTANT: Charge the rechargeable
battery fully before first use. The rechargeable
battery is supplied in DEEP SLEEP MODE, so
it is essential that the rechargeable battery is
charged before first use.
• IMPORTANT: Pay attention to the mains
voltage! The voltage of the power source must
match the information on the type plate of the
rechargeable battery charger.
1. Plug the mains cable (2c) into the appliance
socket on the rechargeable battery charger.
2. Connect the mains cable to the power supply.
3. After charging is completed, remove the mains
cable from the power supply again.
Charging the rechargeable battery
on the EPAC (fig. I)
1. Rotate the locking ring on the connecting
plug (17) one quarter turn to the left and then
pull the connecting plug out of the connec-
tion (14a) of the saddle post with integrated
rechargeable battery (14).
2. Connect the charging plug (2b) to the connec-
tion of the seat post with integrated recharge-
able battery.
3. After charging is completed, remove the
charging plug (2) from the power supply
and reconnect the connecting plug to the
connection of the saddle post with integrated
rechargeable battery.
Removing the rechargeable battery
and charging externally (fig. J)
1. Open the lock (15) with the key (1).
2. Loosen the quick-release lever (27) of the
saddle post with integrated rechargeable
battery (14).
3. Rotate the locking ring on the connecting plug
(17) one quarter turn to the left and then pull it
out of the connection (14a) of the saddle post
with integrated rechargeable battery (14)
(see fig. J.).
4. Pull the saddle post with integrated rechargea-
ble battery gently and evenly out of the frame
(8) to avoid tilting.
Note: The saddle post with integrated recharge-
able battery is lubricated. Mind your clothing.
5. Turn the key in the direction of the arrow and
pull it out.
6. Charge the rechargeable battery (see "Charg-
ing the rechargeable battery").
Note: Bear in mind that removing a component
or a rechargeable battery is not a protection
against theft. The EPAC can also be operated
without assistance from the drive components.
Always protect the EPAC by securing it to some
fixed object with a reliable and tested bicycle
lock.
Inserting the rechargeable
battery (fig. J)
1. Open the lock (15) with the key (1).
2. Insert the saddle (11) and the saddle post with
integrated rechargeable battery (14) into the
saddle tube (35).
3. Plug the connecting plug (17) back into the
connection.
4. Adjust the seat height (see fig. D).
5. Turn the key in the direction of the arrow and
pull it out.
6. Close the quick-release lever (27).
