Inhaltsverzeichnis - Handicare 2000 Installationsanleitung

1 - USED TOOLS AND PARTS
2 - TRACK ASSEMBLY
3 - TRACK ELECTRICAL
4- POWER PACK
5a - STYLE SEAT
5b- SIMPLICITY SEAT
5c- SMART SEAT
6 - TRACK FIXATION
7 - REMOTE CONTROL
8 - CHECK
ATTACHMENTS
2
6
34
48
66
80
94
108
116
126
141
Thank you for choosing a Handicare stairlift.
This manual is for the Handicare 2000 lift with a manual seat
or powered seat type. The manual includes instructions for the
standard and the optional features.
Check stairs [p.06]
Caps [p.08]
First stanchion [p.10]
Second stanchion [p.12]
Position stanchion [p.14]
Top rail-first section [p.16]
Intermediate stanchion [p.18]
Charge wires [p.34]
Pull through spring [p.36]
Earth wire [p.38]
Charger [p.40]
Loading bars [p.48]
Preparing power pack [p.50]
loading power pack [p.52]
Alignment trunnions [p.54]
Remove instal. parts [p.56]
Seat stem [p.66]
Locking bolt [p.68]
looms through stem [p.70]
Seat looms [p.72]
Seat stem [p.80]
Locking bolt [p.82]
looms through stem [p.84]
Seat looms [p.86]
Seat stem [p.94]
Fixation seat back [p.96]
Seat looms [p.98]
Communications [p.100]
Check [p.108]
Tighten bolts [p.110]
Magnets [p.112]
Apply grease [p.114]
Mounting [p.116]
Linking [p.118]
Repeater [p.120]
Measurements [p.126]
Swivel - safatybelt [p.128]
Option functions [p.130]
Safety limits [p.132]
A - Hinge rail [p.142]
B - Emergency operation{TR} [p.146]
C - Emergency operation{SM} [p.148]
INSTALLATION MANUAL
CONTENT
Last stanchion [p.20]
Top rail-sec. section [p.22]
Alignment check [p.24]
Bottom rail-sec. section [p.26]
First stanch.-sec. section [p.28]
Remaining stanchion [p.30]
Check track [p.32]
Terminal block [p.42]
Place charger [p.44]
Power supply [p.46]
Powered footrest [p.58]
Footrest loom [p.60]
Gas strut [p.62]
Carry handle [p.64]
Connectors [p.74]
Dipswitches [p.76]
Closing front cover [p.78]
Connectors [p.88]
Dipswitches [p.90]
Closing front cover [p.92]
Seat base wiring [p.102]
Upholstery [p.104]
Closing front cover [p.106]
Changing channels [p.122]
Check [p.124]
Armrests [p.134]
Keyswitch - stops [p.136]
Declaration [p.138]
D - Emergency operation{SL} [p.150]
E - Competence [p.152]
