7. TECHNICAL SPECIFICATIONS

7.1. TECHNICAL CHARACTERISTICS

Connectors
LAN input connectors:
Max voltage between inputs:
Cables which can be tested
Cable type:
Category:
Reference guideline:
Max cable length:
(*) To perform the "SPLIT PAIR" test, the cable must be at least 1m (3.3ft) long

7.2. GENERAL CHARACTERISTICS

Power supply
Battery type:
Low battery indication:
Battery life:
Auto Power OFF:
Mechanical features
Dimensions (L x W x H):
Weight (battery included):
Dimensions remote units:
Weight remote units:
Mechanical protection:
Environmental conditions of use
Working temperature:
Working humidity:
Storage temperature:
Storage temperature:
Max height of use:
This product conforms to the prescriptions of the EMC directive
This instrument satisfies the requirements of 2011/65/EU (RoHS)
directive and 2012/19/EU (WEEE) directive)
7.3. ACCESSORIES

7.3.1. Standard accessories

•
Remote unit #1
•
Remote unit #2
•
Patch cables RJ45/RJ45, STP, 20cm, 3 pcs
•
Battery (not fitted)
•
Carrying bag
•
User manual

7.3.2. Optional accessories

•
Remote unit #3 and cable RJ45/RJ45 STP
•
Remote unit #4 and cable RJ45/RJ45 STP
•
Remote unit #5 and cable RJ45/RJ45 STP
•
Remote unit #6 and cable RJ45/RJ45 STP
•
Remote unit #7 and cable RJ45/RJ45 STP
•
Remote unit #8 and cable RJ45/RJ45 STP
•
Remote units #3-#8+ 6 cables RJ45/RJ45 STP
29
QUICKLAN6055
RJ45
60VAC/DC
UTP, STP
CAT3, 5, 5E, 6, 6A, 7
TIA/EIA 568B
up to 200m (656ft) (*)
1x9V type IEC 6F22
symbol " " on the display
ca 600h (backlight OFF)
ca 16h (backlight ON)
after 4minutes of idleness (not disabled)
190 x 65 x 45mm (7 x 3 x 2in)
235g (8 ounces)
30 x 25 x 27mm (1 x 1 x 1in)
13g
IP40
0°C ÷ 40 °C (32°F ÷ 104°F)
<80%RH
0°C ÷ 40°C; (32°F ÷ 104°F)
<80%RH
2000m (6562ft
2014/30/EU
Cod. CH1
Cod. CH2
Cod.YAAMS0000000
Cod. REM3
Cod. REM4
Cod. REM5
Cod. REM6
Cod. REM7
Cod. REM8
Cod. REM38
