2. GENERAL DESCRIPTION

The instrument allows the following functions:
•
Wire mapping test on LAN cables with RJ45 connector
•
Test on UTP and STP cables
•
Up to 6 identified error conditions
•
Recognition of up to 8 remote units
•
Pass/Fail indications
•
Backlight
•
Auto Power OFF

3. PREPARATION FOR USE

3.1. INITIAL CHECKS

This instrument was checked both mechanically and electrically
prior to shipment. All possible cares and precautions were taken to
let you receive
Notwithstanding we suggest you check it rapidly (any damage may
have occurred during transport). Make sure that all standard
accessories mentioned in § 7.3.1 are included. Should you have to
return back the instrument for any reason please follow the
instructions mentioned in § 8

3.2. POWER SUPPLY

The instrument is battery supplied with 1x9V alkaline battery type
IEC 6F22 included in the package. When the "
indication symbol is displayed replace battery immediately,
following the instructions given in § 6.2. Don't replace the battery
while the instrument is connected to the plant
3.4 STORAGE
After a period of storage under extreme environmental conditions
exceeding the limits mentioned in § 7.2 let the instrument return to
normal measuring conditions before using it).
20
the instrument in
QUICKLAN6055
perfect conditions.
" low battery
