6 MAINTENANCE
• Only skilled and trained technicians should perform maintenance
operations. Before carrying out maintenance operations, disconnect all
cables from the input terminals.
• Do not use the adapter in environments with high humidity levels or high
temperatures
6.1
CLEANING THE ADAPTER
Use a soft and dry cloth to clean the adapter. Never use wet cloths, solvents, water, etc.
6.2
END OF LIFE
CAUTION: the symbol on the adapter indicates that the appliance and its
accessories must be collected separately and correctly disposed of.
7 TECHNICAL SPECIFICATIONS
Input voltage:
Connection to EVSE:
Recharging stations:
PP Simulation:
CP Simulation:
Simulation EVSE fault:
CP output signal:
Allowed output load:
Protection fuse:
Safety:
Reference guidelines:
Insulation:
Measurement category:
Pollution degree:
Dimensions (L x W x H):
Weight (with integrated cable):
Mechanical protection:
Working temperature:
Working humidity:
Storage temperature:
Storage humidity:
Max operating altitude:
This adapter complies with requirements of EMC 2014/30/EU directive
This adapter complies with requirements of European Directive 2011/65/EU (RoHS)
7.1
ACCESSORIES
7.1.1
ACCESSORIES PROVIDED
• Cable for connection to HT tester
• Carrying case
• User manual
CAUTION
190V ÷ 415V AC Phase-Phase, 50/60Hz ±5%
110V ÷ 240V AC Phase-Neutral, 50/60Hz ±5%
integrated cable with Type 1 and Type 2 plug
length 60cm
charging modes 2 and 3
NC,13A, 20A, 32A, 63A
status A, B, C, D, ventilation/not ventilation
Fault PE, Fault E
PWM communication protocol, 12V
240V, 50/60Hz, max 10A AC
Fast type 250V/10A (5x20mm) (0.2x0.8in)
IEC/EN61010-1
IEC/EN61851-1, IEC/EN60364-7-722
double insulation
CAT III 300V
2
210 x 115 x 60mm (8 x 5 x 2in)
900g (32ounces)
IP40
0°C 40°C (32°F 104°F)
<80%RH
-10°C 60°C (14°F 140°F)
<80%RH
2000m (6562ft)
and 2012/19/EU (WEEE)
EN - 10
EV-TEST100
Code C100EV
