PCD41
42
Technical data - mechanical design
Operating temperature
Storing temperature
Relative humidity
Core cross-section
Protection DIN EN 60529
Operation / keypad
Housing type
Dimensions W x H x L
Cutout dimensions
Installation depth
Mounting
Weight approx.
Material
Technical data - trigger level
Comparator inputs
Control inputs
Input level
Input level Low
Input level High
Input resistance
Relay outputs
Switching voltage max.
Switching current max.
Switching capacity max.
Relay responding time
6.1

Dimensions

6.2

Error messages

Err 1 and Err 2: error must be repaired at factory.
www.baumer.com
0...+50 ºC
-20...+70 ºC
80 % non-condensing
1.5 mm
2
IP 65 face with seal
Membrane with softkeys
Housing for control panel installation
96 x 48 x 124 mm
94 x 44 mm (-0.6)
124 mm
Front panel installation by clip frame
350 g (AC), 250 g (DC)
Housing: Makrolon 6485 (PC)
Input circuit
PNP-logic
Programmable
0...2 VDC
3...40 VDC
3 kΩ
Output circuit
250 VAC / 110 VDC
1 A
150 VA / 30 W
5 ms
