Baumer PCD41 Betriebsanleitung Seite 37

Line 46
Line 51
Line 52
Line 53
Line 54
Line 55
Line 56
Turn off programming Press
Reset to factory setting Turn on instrument and simultaneously press the keys
Tare function via
0 * without Tare function
1 with Tare function
Baud rate
0 * 4800 baud
1 2400 baud
2 1200 baud
3 600 baud
Parity
0 * even
1 odd
2 no
Stop bits
0 * 1
1 2
Address
* from 0 to 99
Assignment output value via interface (line 31 or 32=4)
0 * F
1 HIGH
RS422: control contacts T+ and/or T-
0 * switched in sense of transmission when sending, in sende of
reception when receiving
1 always in sense of transmission
The dash line signalizes the end of the third programming field.
key.
● The instrument then switches back to the operating mode.
All values already programmed are set back to factory setting.
„ClrPro" is then displayed.
www.baumer.com
key
PCD41
and .
37
