Operating Mode - Baumer Pcd41 Betriebsanleitung

Parameter reading It is possible to switch to the next operation parameter with
Peak value reset 1.
Parameter setting 1. Have parameters displayed.
Reading of operation
parameter
Read
Reset
Read
Example

4 Operating mode

The following chapter will inform you on the operation.
● The controller is automatically on the operating mode after the
voltage supply has been turned on.
In the operating mode it is possible to:
- read and, if necessary, to clear the current display status;
- read and, if necessary, to clear the peak;
- adjust the display for the initial and final values;
- to read and modify the limit values P1 and P2.
It is possible to disable all operation parameters on the programming
line (line 11-16).
Key functions
Have the peak value displayed.
2. Press key.
2. Press key and select desired decade; the chosen decade
position flashes.
3. Press key and enter value desired.
To set further decades, repeat steps 2 and 3.
4. Confirm the parameters entered via
Should no confirmation occur within 15 s, the previous setting
will remain valid.
1. Press key. An infotext will appear for approx. 1 s regarding
the displayed operation parameter (e.g.: F for the current mea-
surement).
F - Current measurement
After having turned on the instrument or upon selection via the
key, appears for 1 s, afterwards the current measure-
ment.
HIGH - Peak memory
➜ Press key.
HIGH appears for 1 s on the display, afterwards the peak value.
➜ Press key.
bFdn - Display adjustment initial value
➜ Press key.
bFdn appears for 1 s on the display, afterwards the initial value.
When measuring rotational speed, 0...10 V correspond to a speed
of 0...1000 rpm. The setting of the initial value remains at 0.
www.baumer.com
PCD41
key.
key.
31
