Configuring Engraving Parameters: Speed, Energy, and Size
1. The recommended engraving speed stands at 1000, a value refined through repeated
experimentation. Naturally, you can adjust this speed higher or lower based on your
preference. Opting for a faster speed will save time but might compromise the engraving
quality, while a slower speed yields the opposite effect.
2. In the laser mode, two instructions are available: M3 and M4. For "bit jitter" mode
engraving, it's advisable to use the M4 instruction, while the M3 instruction suits other
scenarios. If your laser supports only M3, verify whether the laser mode is configured in
GRBL settings. For detailed guidance on GRBL configuration, refer to LaserGRBL's official
instructions.
3. Selection of engraving energy should align with the specific material being used.
4. To finalize, adjust the size parameter and then activate the process by clicking the
"Create" button, completing the setup for all engraving parameters.
Saving the GCODE File
Access the top menu of the software interface and click "File." From the dropdown menu,
choose "Save." Afterwards, transfer the saved .nc file onto the TF card. Insert the TF card into
the engraver to employ the file for your engraving task.
For the addition of preview codes to Gcode files, employ the "MKSLaserTool" software within
the TF card.
Default engraving speed is 1000 and can be
adjusted as required
Setting energy value. Improper energy value
will affect the engraving effect
Enter the size of the graph you want to
engrave
