1.
Introduction
Manufacturer:
Scheppach GmbH
Günzburger Str. 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Exclusion of liability
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling,
• Non-compliance with the operating manual,
• Repairs carried out by third parties, unauthorised spe-
cialists,
• Installing and replacing non-original spare parts,
• Application other than specified.
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / 0113 not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of
the product. In addition to the safety instructions in this
operating manual, you must also observe the regula-
tions applicable to the operation of the product in your
country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2. Device description
1.
Saw blade guard
1a.
Locking pin
2.
Riving knife
2a.
Fixing screw
3.
Saw blade
3a.
Inner flange
34 | GB
3b.
Outer flange
3c.
Flange screw
4.
Saw table
5.
Stop rail
6.
Parallel stop
6a.
Sight glass
6b.
Wing nuts
6c.
Washer
6d.
Coach bolt
6e.
Allen screws
7.
Table width extension
8.
Cross member table width extension
9.
Right-hand parallel stop guide (incl. scale)
10.
Reset button
11.
Angle adjustment clamp
12.
Hand wheel
13.
On/off switch
14.
-
15.
Machine stand leg
16.
Cross member, machine stand (short)
16a. Cross member, machine stand (long)
17.
Anti-tip bar
18.
Rubber foot
19.
Parallel stop clamp
20.
Left-hand parallel stop guide (incl. scale)
21.
Transverse cutting gauge
21a. Locking handle
21b. Stop rail
21c. Wing nut
22.
Suction port
23.
Table inlay
23a. Philips screws
24.
Saw blade bearing + ring spanner
3. Scope of delivery
Item
1
6
7
8
9
15
16
www.scheppach.com
Quantity
Designation
1x
Saw blade guard
1x
Parallel stop
2x
Table width extension
Cross member table width
4x
extension
Right-hand parallel stop guide
1x
(incl. scale)
4x
Machine stand leg
Cross member, machine
2x
stand (short)
