Mounting the rear-mounted torsion
spring shaft (HL)
Note that the following instructions only
describe the differences to the assembly of
the front-mounted torsion spring shaft (VL
version). If the assembly steps are identical
to the VL version, there is only a reference to
the respective assembly chapter of the VL
version. Follow the assembly instructions for
the VL version on the respective passages.
4.7.1 HL – Preassembling the door frame
Follow the instructions and Fig.
chapter: 4.4.1 - Preassembling the door frame.
Note that Fig.
b
only refers to the VL variant and
does not apply here.
4.7.2 HL – Mounting the wall anchors
Follow the instructions and illustrations of chapter:
4.4.2 - Mounting the wall anchors.
4.7.3 HL – Mounting the plugs for the door
frame
Follow the instructions and illustrations of chapter:
4.4.3 - Mounting the plugs for the door frame.
In Fig.
e
, page A5., observe the HL version: The
angle frame (1L/1R) is screwed on the garage wall by
means of one screw (S8) and the suitable plug (S9).
4.7.4 HL – Preassembling the horizontal rail
pairs
Follow the instructions and illustrations of chapter:
4.4.4 - Preassembling the horizontal rail pairs.
Observe the following differences with regard to the
VL version:
Fig.
b
, page A7. In addition, mount one fastening
profile (100) each to the horizontal rail pair (14L/14R)
by means of the screws (S6) and (S12). In doing so,
note that the screw heads (S6) are mounted towards
the inside to the rail!
Fig.
d
Mount the HL sole plate (21L/21R) to the rail
pair (14L/14R). Use the screws (S11) for this pur-
pose, too.
4.7.5 HL – Mounting the rail pairs to the frame
Follow the instructions and illustrations of chapter:
4.4.5 - Mounting the horizontal rail pairs to the frame.
4.7.6 HL – Suspending the horizontal rail pairs
Follow the instructions and illustrations of chapter:
4.4.6 - Suspending the horizontal rail pairs.
Observe the following differences with regard to the
VL version:
Fig.
d
Using two screws (S6 + S12) each, mount the
rail connector (6) to the HL sole plate (21L/21R) of
both rail pairs (14L/14R).
These assembly, operation and maintenance instructions must be kept for the entire period of use!
Fig.
anchor rail (27), the connection angle (28) and the
screws (S6 + S12). Only fasten the screws lightly to
be able to align the system afterwards. Then use two
screws each (S6 + S12) to mount the pre-assembled
ceiling suspension to the HL sole plate (21L/21R).
4.7.7 HL – Preassembling the centre bearing
Fig.
the base plate (103) by using the screws (S6 + S12).
Fig.
position the rail clips in the rail connector (6).
Fig.
ing (37) to the rail clips (29) with the nuts (S12) and
a
, page A3. of
ensure that the centre bearing can still be shifted.
NOTICE
4.7.8 HL – Mounting the torsion spring shaft
Follow the instructions and illustrations of chapter:
4.4.7 - Mounting the torsion spring shaft.
Fig.
sembled right torsion spring shaft (35R) into the sole
plate (21R) and fasten it using the screw (S11).
Fig.
the torsion spring shaft (35R) and tighten the
screws (S12). Observe the following:
•
•
Fig.
the right torsion spring shaft (35R).
Fig.
same way you mounted the right. Then centrally slide
the shaft coupling (38) over both shaft ends. Only
fasten lightly in order to guarantee a subsequent ad-
justment.
Fig.
ing.
4.7.9 Hl – Replacing the wire rope
Fig.
the HL holder for the deflection roller (101L/101R)
and the safety guard (102L/102R) to the tail
end (16L/16R) and the fastening profile (100).
Fig.
drum on the torsion spring shaft (35L/35R). Remove
the wire cable (104) by loosening the grub screw from
the cable drum and dispose of the wire cable.
Fig.
to
screws (S10).
f
Mount the ceiling suspension consisting of the
a
, page A13. Screw the centre bearing (37) to
b
Insert the screws (S5) in the rail clip (29) and
c
Lightly screw the pre-assembled centre bear-
Doors with a width of basic
dimension exceeding 3530 mm
require two centre bearings (37).
Mount one centre bearing (37) per side
and per torsion spring (35L/35R) to the
rail connector (6).
a
and Fig.
b
, page A14. Slide the preas-
c
and Fig.
d
Slide the centre bearing (37) onto
Ensure a sufficient distance to the torsion spring
shaft (35R) which should at least be 120 mm.
Also consider to leave sufficient space for the
shaft coupling (38) and its installation.
f
Slide the shaft coupling onto the shaft end of
g
Mount the left torsion spring shaft (35L) the
i
Mount a ceiling suspension to the centre bear-
a
, page A17. Use the screws (S11) to mount
b
Unreel the wire cable (104) from the cable
c
Mount the protective cover for the cable drum
the
HL
sole
plate (21L/21R)
using
the
EN - 27
