Novoferm iso70-2 TW Original-Montage- Und Betriebsanleitung Seite 22

Sektionaltore mit torsionsfederwelle

Werbung

Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 3
3.2
Technical data
Model specifications
Product:
Door size / weight
Temperature range:
Sound pressure level L
Manufacturer:
3.3
Rating plate
The rating plate is situated on the inside of the door
leaf.
4
Mounting
4.1
Safety information for installation and
assembly
The installation may only be carried out by
suitably qualified installers, see chapter 2.3 -
Personnel qualifications.
Read these installation instructions before you
start installing the product.
Never carry out the installation on your own.
Some of the work steps can only be achieved
with two people working.
Wear your personal protective equipment upon
installation.
4.2
Scope of delivery
The scope of delivery is determined by the product
configuration. The scope of supply usually comprises
the following:
Packet with sections
Packet with frame
Packet for installation
4.3
Preparing for installation
4.3.1 Information regarding installation
Observe the following information before starting the
installation:
The steps for installation described in these
assembly and operating instructions refer to a
standard installation. Please contact the
manufacturer regarding special mounting
conditions.
22 - EN
iso70-2
see rating plate
+40 °C
-20 °C
≤ 70 dB(A)
pA
Novoferm GmbH
Isselburger Straße 31
46459 Rees (Haldern),
Germany
Germany
www.novoferm.de
Note that the following assembly instructions
describe the assembly of a sectional door with a
front-mounted torsion spring shaft (VL). If a rear-
mounted torsion spring shaft (HL) is to be
mounted, also observe the instructions in
chapter: 4.7 / – Mounting the rear-mounted
torsion spring shaft (HL).
Prior to assembly, preventively compare the
dimensions of the garage by comparing them to
the basic dimensions of the door.
– minimal internal width of the garage = width of
basic dimension + 160 mm
– For VL: minimum garage height up to ceiling =
height of basic dimension + 245 mm
– For HL: minimum garage height up to ceiling =
height of basic dimension + 115 mm
– minimum width stop, right and left = 35 mm
Check the dimensions of the garage door
opening and compare them to the dimensions
specified on the delivery note.
Check whether the supplied wooden screws (S8)
and the plugs (S9) are suitable for the respective
structural conditions.
All right/ left specifications regarding the
installation refer to the perspective from the
inside of the garage, i.e. the viewing direction is
towards the outwards direction!
All specified dimensions are in millimetres.
Subject to technical changes.
4.3.2 Required tools
Fig.
a
, page A2. For assembly, you require the
following tools (put into the garage prior to the install-
ation of the door, if no other access is available):
wooden folding rule or tape measure
reversible ratchet with extension
wrench set with SW 7, 10, 13 and T30 (if
required, also jaw spanners or socket wrenches)
cross-tip screwdriver Phillips; size 2
T30 screwdriver
impact drill
10 mm drill (drill length at least 200 mm)
chalk for marking
wire rope shears or heavy-duty side cutter
cutter knife
spirit level (min. 80 cm)
hacksaw
water pump pliers
hammer
chisel
min. two screw clamps
ladders and support aids, if required
personal protective equipment
These assembly, operation and maintenance instructions must be kept for the entire period of use!
