Put the centre bearings (37) in place with a slight
offset to the centre of the door in order to leave
space if a door drive will be installed.
•
Choose a suitable reference point (upper edge of
angle frames 1R and 1L, garage ceiling) to
determine the position of the centre bearing.
Fig.
e
Screw the centre bearing in place by using the
screws (S8) and the plugs (S9).
Fig.
f
Slide the shaft coupling onto the shaft end of
the right torsion spring (35R).
Fig.
g
and Fig.
h
Mount the left torsion spring
shaft (35L) the same way you mounted the right.
Then centrally slide the shaft coupling (38) over both
shaft ends. Only fasten lightly in order to guarantee a
subsequent adjustment.
4.5
Mounting the door leaf
4.5.1 Premounting the bottom section
Fig.
a
Fig.
b
, page A18. Always remove the pro-
tection film on every door segment by carefully
carving into the protection film along the end cap,
then pull off the film.
Fig.
c
Fig.
d
Attach the logo (58) to the outside of
the bottom section (44), then fasten the bottom
grip (49) on the inside by means of the screws (S13).
When screwing, observe the permissible torque of
10 Nm.
4.5.2 Mounting the bottom section
Fig.
a
, page A19. Clean the seals of the angle
frames (1L/1R) with a damp cloth. Position the bot-
tom section (44) in the door frame and secure it
against toppling over.
Fig.
b
Fig.
c
On the left and right on the top, mount
an external hinge (48) with a tandem wheel (56): In-
sert one tandem wheel (56) each into an external
hinge (48), then insert the track roll into the vertical
guide rail. Tighten the external hinges (48) on the bot-
tom section (44) with two screws (S13) each. When
screwing, observe the permissible torque of 10 Nm.
Fig.
d
Fig.
e
Unreel the wire cable (104) from the
torsion spring shaft (35L/35R). Feed the wire
cable (104) behind the mounted track rollers (56) and
put it on the bolt of the mounting (57L/57R) along with
the cable eye and the plastic bushing (59). Secure
the wire cable (104) with the split pin (60).
Fig.
f
On the left and right at the bottom, attach the
mountings (57L/57R) to the bottom section (44) by
means of the screws (S13). When screwing, observe
the permissible torque of 10 Nm.
Fig.
g
Insert the lower track rollers (50) into the ver-
tical rails and screw the rails to the mount-
ings (57L/57R) by means of the screws (S5+S12).
These assembly, operation and maintenance instructions must be kept for the entire period of use!
4.5.3 Horizontally aligning the door leaf
Fig.
a
Fig.
b
, page A21. Wind the wire
cables (104) up by approx. a half-turn (prestressed)
so that they are under slight tension. By means of the
spirit level, check whether the bottom section (44) is
aligned horizontally. If required, adjust it at the torsion
spring shaft (35L/35R).
Fig.
c
Afterwards, tighten the shaft coupling (38).
4.5.4 Adjusting the track rollers
Re-adjust the tandem wheels every time you insert
another door segment. This allows you to have a
good insight on the distance between the sliding strip
of the frame and the inserted door segment. In doing
so, observe the following settings for different door
drive types.
Fig.
a
, page A22. Loosen the screw (56a) for ad-
justing the tandem wheels (56).
Fig.
b
Hand operation and ceiling pull: Adjust all
tandem wheels (56) and the bottommost track
roller (50) in a way that the door segment's distance
to the sliding strip is approx. 1.5 – 2 mm (pull rolls in
direction of the arrow).
Fig.
c
Novoport drive: Adjust the lower tandem
wheels (56) and the bottommost track roller (50) as
described before. On the Novoport side, inverse the
running direction of the topmost tandem wheel (56) in
order to pull the door leaf away from the sliding edge.
Make sure that the track rollers can be turned easily
by hand.
4.5.5 Mounting the lock section
Fig.
a
, page A22. Position the lock section (67) in
the door frame and secure it against toppling over.
When inserting the section, check groove and spring
connector between the sections for proper fit.
Fig.
b
Screw the lock section to the bottom sec-
tion (44) below on the external hinges (48). Mount the
upper
external
hinges (48)
wheels (56) in the same way as for the bottom sec-
tion (44). When screwing, observe the permissible
torque of 10 Nm.
4.5.6 Mounting the lock (optional)
Mount the lock set to the lock section according to the
illustrations.
Fig.
a
, page A23. Insert the lock plate (72) with the
cover plate (71) from the outside into the rectangular
hole on the lock section (67), then screw it in place
with the lock set (73, 76) from the inside by means of
the screws (S1).
Fig.
b
Push the outer handle (70) through the holes
of the lock (the rotating arm must point upwards) and
screw the outer handle (70) together with the inside
handle (78) from the inside by means of the
screw (S2).
Fig.
c
Insert the bolt bar (80) into the bolt catch (79).
and
the
tandem
EN - 25
