PAA, Process Image „Universal Full"
Byte Bit Kategorie
0 .0 Digital Outputs
PLC Output
0 .1 Digital Outputs
PLC Output
0 .2 Digital Outputs
PLC Output
0 .3 Digital Outputs
PLC Output
1 Motor RD 1
2 Motor RD 2
3 Motor RD 3
4 Motor RD 4
5 .0 Control Inputs
Overwrite
5 .1 Control Inputs
Overwrite
5 .2 Control Inputs
Overwrite
5 .3 Control Inputs
Overwrite
5 .4 Control Inputs
Overwrite
5 .5 Control Inputs
Overwrite
5 .6 Control Inputs
Overwrite
5 .7 Control Inputs
Overwrite
Bedienen und Programmieren
Bezeichnung Typ
Output 1 BOOL
Output 2 BOOL
Output 3 BOOL
Output 4 BOOL
Speed1 SINT8
Speed2 SINT8
Speed3 SINT8
Speed4 SINT8
ControlInput1 BOOL
ControlInput2 BOOL
ControlInput3 BOOL
ControlInput4 BOOL
ControlInput5 BOOL
ControlInput6 BOOL
ControlInput7 BOOL
ControlInput8 BOOL
Prozessdaten
Kommentar
Speed 0 - 100
(0 = Stopp, 100 = max.
Speed), negatives Vorzeichen
kehrt Drehrichtung um
Stopp Zone 1
Stopp Zone 2
Stopp Zone 3
Stopp Zone 4
Stopp Zone 5
Stopp Zone 6
Stopp Zone 7
Stopp Zone 8
