Interroll MultiControl Bedienen Und Programmieren Seite 96

Byte Bit Kategorie
16 System State
18 System State
20 System State
22 System State
26 .0 Control Inputs
26 .1 Control Inputs
26 .2 Control Inputs
26 .3 Control Inputs
28 .0 Control Outputs
28 .1 Control Outputs
28 .2 Control Outputs
28 .3 Control Outputs
29 .0 Handshake
Signals
29 .1 Handshake
Signals
29 .4 Handshake
Signals
29 .5 Handshake
Signals
29 .6 Handshake
Signals
29 .7 Handshake
Signals
Bedienen und Programmieren
Bezeichnung Typ
Voltage_Motor INT
Voltage_Logic INT
Temperature INT
SystemUpTime DINT
ControllInput 1 BOOL
ControllInput 2 BOOL
ControllInput 3 BOOL
ControllInput 4 BOOL
Control Output1 BOOL
Control Output2 BOOL
Control Output3 BOOL
Control Output4 BOOL
In_Up BOOL
In_Down BOOL
Out_Up BOOL
Out_Down BOOL
Out_Left BOOL
Out_Right BOOL
Prozessdaten
Kommentar
Spannung „Motor Power"
in mV
Spannung „Power Logic
+ Sensors" in mV
Temperatur in 0,1 C
Betriebszeit in Sekunden
seit letztem Start /
Neustart
Stop Zone 1
Stop Zone 2
Stop Zone 3
Stop Zone 4
High = Zone 1 belegt
High = Zone 2 belegt
High = Zone 3 belegt
High = Zone 4 belegt
Startsignal erste Zone
Startsignal Endzone
High / Low = Zone free /
busy
