Interroll MultiControl Bedienen Und Programmieren Seite 93

Prozessdaten
Beschreibung
Handshake Up Out
Handshake Down Out
Handshake Left Out
Handshake Right Out
Control Input 1
Control Input 2
Control Input 3
Control Input 4
Handshake Up In
Handshake Down In
Handshake Left In
Handshake Right In
PAA
Control Input 1
Control Input 1
Control Input 1
Control Input 1
Handshake Up In
Handshake Down In
Handshake Left In
Handshake Right In
88
Typ Byte Bit
BOOL 29 .4
BOOL 29 .5
BOOL 29 .6
BOOL 29 .7
BOOL 26 .0
BOOL 26 .1
BOOL 26 .2
BOOL 26 .3
BOOL 29 .0
BOOL 29 .1
BOOL 29 .2
BOOL 29 .3
BOOL 5 .0
BOOL 5 .1
BOOL 5 .2
BOOL 5 .3
BOOL 8 .0
BOOL 8 .1
BOOL 8 .2
BOOL 8 .3
Process Image
Byte Bit Byte Bit
11 .4
11 .5
11 .6
11 .7
9 .0
9 .1
9 .2
9 .3
11 .0
11 .1
11 .2
11 .3
5 .0
5 .1
5 .2
5 .3
7 .0
7 .1
7 .2
7 .3
Bedienen und Programmieren
Byte Bit Byte Bit
6 .4
6 .5
6 .6
6 .7
4 .0
4 .1
4 .2
4 .3
6 .0
6 .1
6 .2
6 .3
0 .0
0 .1
0 .2
0 .3
2 .0
2 .1
2 .2
2 .3
