2.8. PRODUCT SPECIFICATIONS
Below are the specifications of the product at the
time of printing. Gendex reserves the right to
Camera (handpiece)
Equipment Model
AcuCam Concept IV
Weight
0.4 Kg (0.9 lbs.)
Width of Handpiece
19.0 mm (0.75 inch)
Length of Handpiece
190.5 mm (7.5 inches)
Height of Handpiece
19.0 mm (0.75 inch)
Resolving Power
80 LP/mm
Angle of View
62˚
Direction of View
97.5˚ to handpiece center line
Focal Range
1 mm to infinity
Charged Coupled
0.25 inches
Device
CCD Pixels
PAL 437,600
NTSC 379,300
Power Supply
Input Voltage Range
Auto-range
100-120VAC / 200-240 VAC
47-63 Hz
Output Voltage
12 VDC
Input Power Rating
3.4 Amps MAX
3 Amps @ 115VAC
1.7 Amps @ 230 VAC
FireWire is a registered trademark of Apple Computer Inc.
registered in U.S. and other countries.
FireWire is a term Apple trademarked for technology that is defined in the IEEE-1394a specification.
Similarly, Sony uses the term i.LINK to describe the same technology.
FWT
AcuCam Concept IV
change the design and specifications at anytime
without notification.
Docking Station
Equipment Model
Digital Output
Analog Output
Power Consumption
Lamp
Weight
Width
Length
Height
Maximum FireWire
cable length
supported
12
FWT
AcuCam Concept IV
IEEE-1394a, FireWire,
i.LINK
480 TV Lines
7 Amps @ 12 V
12V 75W halogen bulb
USHIO PN 1000835
Average bulb life: 2,000 hrs.
1.1 Kg (2.5 lbs.)
165 mm (6.5 inches)
Add 30 mm (1.2 inches) for
Holster
165 mm (6.5 inches
74 mm (3.0 inches)
4.5 m (15 feet)
Operation Manual and Installation Guide
