6.4 Trimmer
VA Opening speed. Adjust the opening speed.
VC Closing speed. Adjust the closing speed only when contact 0-1 is connected to the BRAKE card
and DIP5=ON.
Adjustments according to the operating forces. Without 0-1 connection to the BRAKE card and
DIP5=OFF. Perform the following steps:
- Set the trimmer VC=MAX. Adjust the correct closing speed as indicated in paragraph 6.7 and
ensure that the manoeuvering force and the thrust between the door and the obstacle is lower
than the values set out by regulation DIN 18650-1.
- Reduce the trimmer VC adjustment and perform the opening and closing manoeuvers. Repeat
this step until you find the VC trimmer position that causes the POWER ALARM LED to light
up.
- Increase by approx. 20% the VC trimmer adjustment.
TC Automatic closure time. It adjusts the time that elapses between the ending of opening control
and the beginning of the automatic closing. Time is renewed by controls 1-3A, 1-3B, H-3A, H-3B
and 41-8.
RF Motor torque. It adjusts motor torque.
RF trimmer also adjusts thrust on obstacles.
If an obstacle is present, during opening operation it stops movement, whereas during closing
operation it reverts movement.
After the obstacle has been removed, the door automatically searches for its stop and continues its
stroke at learning speed. If an opening control is given with the door locked, the following opening
operation will be disabled for 30 s.

6.5 Dip-Switches

Doors with electric lock. When the door is closed a closing force is maintained by the motor
or the spring. The electric lock connected to the LK terminals is powered with a 0.1 advance
before door opening.
Doors with no electric lock and subject to strong winds. If the wind blows the door open,
a closing thrust is triggered by the motor or by the spring.
Description
DIP3 Electric lock fastening.
DIP4 Electric lock type.
DIP5 Spring closing.
DIP6 Low energy.
6.6 Jumper
Description
J1 Arm type
J2 Closing spring
J3 FUTURE USE
Description
Description
OFF
Disabled.
Standard.
The electric lock or electric block is ge-
nerally powered off. When powered it
allows door opening.
Spring closing
With 0-1 not connected to BRAKE card.
Disabled.
WELBA articulated arm
WELF
23
Enabled.
At approx. 20° from the closing stop,
the door thrust/speed increases to
allow proper fastening when electric
locks or electric blocks are present.
DO NOT USE
Motor closing
With 0-1 connected to BRAKE card.
With power supply present the door is
closed by motor whereas with power
supply off by spring.
DO NOT USE
OFF
DO NOT USE
DO NOT USE
/
MIN. MAX.
20 °/s 60 °/s
4,5 s/90° 1,5 s/90°
20 °/s 60 °/s
4,5 s/90° 1,5 s/90°
0 s 30 s
60 % 100 %
0 % 100 %
DIP1 DIP2
OFF ON
OFF OFF
ON
ON
/
