SAFETY MEASURES
Figure 4
In order to do so, lift the winder, set the safety locks (S) into the secured position and secure by means of spring U-bolts (H).
Before carrying out any work, unlock the safety locks (S) and block in the spring U-bolt (H).
2.8
Safety stickers with warning symbols
Although the rapeseed header extension is equipped with all safety devices, it is not possible to completely secure all danger
zones on the machine while maintaining functionality. For this reason, so-called warning pictographs are attached to the
machine. These pictographs inform you about the existing residual risks. Please make sure to keep the warning pictographs in
perfect condition – this ensures your own safety! If required, you can purchase the warning pictographs from us by specifying
the order no..
•
Immediately replace damaged and illegible stickers!
•
When repairing or replacing parts, replace the corresponding warning pictographs!
•
When carrying out cleaning work, ensure that warning pictographs are not damaged!
•
Make yourself familiar with the statements of the warning pictographs and danger zones on the machine!
In the following section, the positions and meanings of the warning pictographs are briefly explained:
Figure 6
Do not open or remove the protection device with the motor running.(Fig.1, 2)
Figure 8
Read and observe the operating instructions before using the machine! Fig. 3,4)
CAUTION!
Never use the winder safety locks as supports of the winder when driving on public traffic
roads. This may lead to damage to the hydraulic cylinder.
