Device Settings
Keys: , , ,
Field handling
Key:
Codepage
Taste:
External parameters
Key:
Buzzer
Display
Key:
Language
Key:
Keyboard layout
Key:
Customized entry
Key:
Hotstart
, ,
Off: The complete print memory is deleted.
Keep graphic: A graphic res. a TrueType font is transferred to the direct print module once and
stored in the direct print module internal memory. For the following print order only the modified
data is transferred to the direct print module. The advantage is the saving of transmitting time
for the graphic data.
The graphic data created by the direct print module itself (internal fonts, bar codes, ...) is
generated only if they were changed. The generating time is saved.
Delete graphic: The graphics res. TrueType fonts stored in the internal memory is deleted but
the other fields are kept.
Restore graphic: At the end of the print order the printed order can again be started at the
direct print module. All graphics and TrueType fonts are again printed.
Exception: With column printing always full columns must be printed (number of pieces always
multiple of the columns). Deleted columns are not restored.
Indication of the font used in the direct print module.
The following possibilities are available:
ANSI character set / Codepage 437 / Codepage 850 / GEM German / GEM English / GEM
French / GEM Swedish / GEM Danish.
Layout dimension only: The parameters for layout length, gap length and layout width can be
transferred to the printing system. All other parameter settings are to be made directly at the
printing system.
On: Sending parameters such as print speed and contrast via our layout creation software to
the direct print module. Parameters which are set directly at the direct print module before are
no longer considered.
Off: Only settings made directly at the direct prin module are considered.
On: An acoustic signal is audible when pressing a key.
Value range: 1 ... 7.
Off: No signal is audible.
Setting of display contrast.
Value range: 45 ... 75.
Selection of language in which you want to display the text in the display.
At the moment the following languages are available: German, English, French, Spanish,
Finnish, Czech, Portuguese, Dutch, Italian, Danish, Polish, Greek, Hungarian, Russian, Chinese
(option), Ukrainian, Turkish, Swedish, Norwegian.
Selection of region for the desired keyboard layout. The following possibilities are available:
Germany, England, France, Greece, Spain, Sweden and US.
Off: No question appears at the display. In this case the stored default value is printed.
On: The question referring the customized variable appears once before the print start at the
display.
Auto: The questions referring the customized variable and the quantity query appear after every
printed layout.
Auto without quantity query: The question referring the customized variable appears after
every layout without additional query for the quantity.
On: Continue an interrupted print order after switching on the module anew.
(Only if module is equipped with option Compact Flash card)
Off: After switching off the direct print module the complete data is lost.
