Connect the Direct Print Module
The direct print module is equipped with a versatile power supply unit. The device may be operated with a mains voltage of
110 ... 230 V AC / 50 ... 60 Hz without any adjustments or modifications.
CAUTION!
The direct print module can be damaged by undefined switch-on currents.
Set the power switch to '0' before plugging in the direct print module.
Insert the power cable into the power connection socket.
Insert the plug of power cable into a grounded electrical outlet.
NOTICE!
Insufficient or missing grounding can cause faults during operation.
Ensure that all computers and connection cables connected to the direct print module are grounded.
Connect the direct print module to a computer or network with a suitable cable.
Before Initial Operation
Mount the print mechanics.
Connect all cables between the print mechanics and control unit.
Protect the cables against unintentional unscrewing.
Connect the compressed air line.
Connect the control unit and PC by printer interface.
Connect the control unit and packaging machine by inputs and outputs.
Connect the power cable of control unit.
Print Control
The print is started by a start signal to the 'print start-control input'. So that the control unit detects when the start signal can be
set, it is possible and mostly necessary to track the print status via the control outputs. (serial, USB or Ethernet). The print is
started by a start signal to the 'print start-control input'. So that the control unit detects when the start signal can be set, it is
possible and mostly necessary to track the print status via the control outputs.
Initial Operation
After all the connections are completed, switch on the control unit.
The main menu appears which shows the model type, current date and time.
Insert the ribbon cassette.
After loading the transfer ribbon cassette the measuring of transfer ribbon begins and the printhead is moved to the print
position.
