Dynacode IP
Ribbon Save - Intermittent Mode
Keys: , , ,
Mode
Mode: Standard
Transfer ribbon correction
Key:
Expert parameters
Key:
Printhead down time
Printhead up time
Key:
Printhead valve reaction
time
Key:
Tension
Ribbon Mode
Mode: Shift
X-Shift / Y-Shift
Key:
Lanes / R-Shift
Key:
Expert parameters
130
,
Selection of ribbon save mode.
Off: Ribbon save set to Off.
Standard: Maximum ribbon save performance, i.e. with this setting there is no loss of transfer
ribbon (apart from the safety distance of 1 mm, so the print fields are not printed one into the
other).
Shift: Layout data can be printed several times laterally displaced. A maximum utilization of
transfer ribbon can be achieved.
0 mm = It is always so far retreated that an optimal ribbon save is reached.
Default: 0 mm
−xx mm = The retreat can be made smaller.
+xx mm = The retreat can be made larger.
Password protected menu
Enter password, press key
indicated:
PhDownT = printhead down time in ms:
Is used from ribbon save algorithm to use for the calculation of start time of printhead downward
movement.
PHupT = printhead up time in ms:
Is used from ribbon save algorithm to calculate if a field ribbon save can be made or not.
PhVReactT = valve reaction time in ms:
The time is calculated when to start with printhead upward movement.
Indication of length that is transported forwards after measuring the transfer ribbon.
0: The transfer ribbon is retracted after each printout over the complete print length, i.e. no
ribbon save between the individual layouts.
1: The transfer ribbon is only retracted over the printed sector, i.e. the gaps between the layouts
were not optimised.
When changing the layouts, the transfer ribbon is positioned automatically
X-Shift: Indication of displacement of the printout in X direction.
Y-Shift: Indication of displacement of the printout in printing direction.
Lanes: Indication of number of lanes printed side by side.
R-Shift: Indication of distance when changing to a new lane.
Password protected menu
Enter password and press key
See mode 'Standard' for description of the parameters.
English
to confirm the entry and the following parameters are
to confirm the entry.
