Dynacode IP
Service Functions
NOTICE!
So that the distributor res. the manufacturer in case of service can offer fast support the necessary information such
as selected parameters can be taken directly from the service functions menu of the device.
Keys: , , ,
Photocell parameters
Key:
Paper counter:
Key:
Heater resistance
Key:
Printhead temperature
Key:
Ribbon
Ink side
Key:
Brake power
Key:
Print examples
136
, , , ,
H = cover switch (machines with cover switch only)
0 = open cover
1 = closed cover.
P = compressed air control:
Indication of 0 or 1 for the compressed-air control.
R1 = transfer ribbon rewinding roll
Indication of transfer ribbon rewinding roll status.
4 states are indicated (no marking in photocell, marking from right, marking from left, marking
completely in photocell).
R2 = transfer ribbon unwinding roll
Indication of transfer ribbon unwinding roll status.
4 states are indicated (no marking in photocell, marking from right, marking from left, marking
completely in photocell).
C = Carriage:
Indication of print carriage position.
ENC = Encoder:
Indication of current state of encoder
D: Indication of printhead attainment in meters.
G: Indication of device attainment in meters.
To achieve a high print quality, the indicated Ohm value must be set after replacing the
printhead.
Indication of printhead temperature. The printhead temperature corresponds normally to the
room temperature. In case the maximum printhead temperature is exceeded, the current print
order is interrupted and an error message appears at the printer display.
Selection of the used transfer ribbon length (300 m, 450 m, 600 m, 900 m, 1000 m).
Selection of the coating side of transfer ribbon, either outside or inside.
Default: Coating outside
BrkPow:
Adjustment of brake power for acceleration and braking in %.
BrkPowP:
Adjustment of brake power during printing.
Select this menu item to get a printout with all settings.
Settings:
Printout of all printer settings such as speed, label and transfer ribbon material.
Bar codes:
Printout of all available bar code types.
Fonts:
Printout of all available font types.
