Carl Valentin Dynacode IP53 Kurzanleitung Seite 128

Dynacode IP
Key:
Rotate layout
Key:
Alignment
Ribbon Save - Continuous Mode
Keys: , , ,
Mode
Mode: Standard
Transfer ribbon correction
Key:
Performance information
Key:
Expert parameters
Key:
Printhead down time
Ribbon motor early start
time
128
According to standard the layout is printed ahead with a rotation of 0°. If the function is
activated, the layout is rotated by 180° and printed in reading direction.
The adjustment of layout is effected only after 'flip/rotate layout', i.e. the adjustment is
independent of the functions flip and rotate.
Left: The layout is aligned at the left-most position of printhead.
Centre: The layout is aligned at central point of printhead.
Right: The layout is aligned at right-most position of printhead.
,
Selection of ribbon save mode.
Off: Ribbon save set to Off.
Standard: Maximum ribbon save performance, i.e. with this setting there is no loss of transfer
ribbon (apart from the safety distance of 1 mm, so the print fields are not printed one into the
other).
Shift: Layout data can be printed several times laterally displaced. A maximum utilization of
transfer ribbon can be achieved.
SaveStrt: No start signal loss, direct print module regulates the ribbon save quality
automatically according to requirement.
Speed: Determination of max. print speed.
On the base of this value all necessary calculations.
0 mm = It is always so far retracted that an optimal ribbon save is reached (no loss of transfer
ribbon).
Default: -1 mm
−xx mm = The feedback can be made smaller.
+xx mm = The feedback can be made larger.
sa/mm: The smallest possible distance of two prints with full ribbon save
cmin: Max. number of cycles per minute.
so/mm: Indicates the loss of ribbon save
Password protected menu
Enter password, press key
indicated.
PhDownT = printhead down time in ms:
Is used from ribbon save algorithm to use for the calculation of start time of printhead downward
movement.
REStartT = ribbon motor early start time in ms:
This value is added to the acceleration time of transfer ribbon movement. Time indication for the
time between 'motor reached material speed' and 'printhead burns'.
English
to confirm the entry and the following parameters are
