2.9 Picture appendix

The picture appendix is common for all the language versions. You can find it at the end of this manual in the Chapter 5 on page 53.
A - Complete engine B - Guiding handles
Pict. 1: Machine packaging
1) Complete engine
2) Guiding handles
3) Flange
4) Clutch
5) Front hand rail
6) Centrifugal clutch
7) Handlebars handgrip
8) Left handgrip
Pict. 2: Description of basic elements of driving units
1) Complete engine
2) Gearbox flange
3) Guiding handles carrier
Pict. 3: Driving unit assembly
1) Connection of the cut-out cable with the cut-out on the engine (in factory)
2) Earthing cable eye fixed by screw to the engine (in factory)
3) Fasten the cable to the fuel line with tie clip
4) Pull the cable through the hole in the side plate of the handlebars holder
5) Pull the cable through the gap in the handlebars holder
6) Using two tie wraps fasten the cable to the bottom radius of the handlebars pipe
7) Pull the cable through the hole in the handlebars pipe
8) Safety ignition switch
9) Left handgrip with a groove
10) Earthing cable connector - longer
11) Cut-out cable connector - shorter
12) Push the covering plastic tubing over the connectors of the cut-out cable
13) Screw
14) Washer
15) Right handgrip
16) Accelerator levers with a screw and nut
Pict. 4: Safety ignition switch cable connection, assembly of handgrips and accelerator lever
Pict. 5: The driving unit mounting and securing
Pict. 6: Positions of accelerator lever
Pict. 7: Positions of safety ignition switch
Pict. 8: Handlebars side adjustment
Pict. 9: Handlebars height adjustment
Pict. 10: Positions of handlebars of guiding handles – transport and storage position versions
Pict. 11: Lubricating and servicing points
Spark plug spanner No.21 or 11/16"
Cross-point screwdriver
Canister HONDA
HONDA fuel stabilizer
Hour meter VARI POWERMETER
Pict. 12: Recommended accessories (not included with the machine)
Location on the machine
Pict. 13: Self-adhesive sticker with safety pictographs
9) Right handgrip
10) Safety switch
11) Accelerator lever
12) Handlebars holder carrier
13) Upper joint
14) Tightening nut
15) Joint arresting pin
16) Flange cylindrical part
4) Screws in the flange
5) Flange rear part
6) Flat steel spacer
PJXP200 / PJGCVX200 / PJCV224
17) Quick-operating spring clamp
18) Pin
19) Air filter
20) Fuel valve
21) Tank lid
22) Starter pull cord handle
7) Rubber pad
8) Closing cup
9) Self-locking nut M8 - 5pcs
27
