Danfoss PVG 32 Technische Informationen Seite 234

Technische Informationen
Proportionalventilgruppe PVG 32
PVG 32-Kombinationen, Ventilblockabmessungen
PVB 100/32-Kombination, Ventilblockabmessungen, mm [Zoll]
Anzahl von PVB 100
(vertikal)
1
2
3
4
5
234 | © Danfoss | Dezember 2018
L3
L1
L2
1 2 3
168 216 264
L1
[6,61] [8,50] [10,39] [12,28] [14,17] [16,06] [17,95] [19,84] [21,73] [23,62] [25,51]
L3
216 264 312
L1
[8,50] [10,39] [12,28] [14,17] [16,06] [17,95] [19,84] [21,73] [23,62] [25,51] [27,40]
L3
264 312 360
L1
[10,39] [12,28] [14,17] [16,06] [17,95] [19,84] [21,73] [23,62] [25,51] [27,40] [29,29]
L3
312 360 408
L1
[12,28] [14,17] [16,06] [17,95] [19,84] [21,73] [23,62] [25,51] [27,40] [29,29] [31,18]
L3
360 408 456
L1
[14,17] [16,06] [17,95] [19,84] [21,73] [23,62] [25,51] [27,40] [29,29] [31,18] [33,07]
L3
Archivierung: 08/2020
Anzahl PVB 32-Module
4 5 6 7 8
312 360 408 456 504
80 mm [3,15 Zoll]
360 408 456 504 552
128 mm [5,04 Zoll]
408 456 504 552 600
176 mm [6,93 Zoll]
456 504 552 600 648
224 mm [8,82 Zoll]
504 552 600 648 696
272 mm [10,71 Zoll]
BC152886483664de-DE1101
9 10 11
552 600 648
600 648 696
648 696 744
696 744 792
744 792 840
