Power range Phase 1
0 - 3 kW contin-
0 - 3 kW
uously variable
0 - 3 kW contin-
3 - 6 kW
uously variable
0 - 3 kW contin-
6 - 9 kW
uously variable
Other resistive loads such as infrared heaters, towel dryers, etc. can also be controlled.
WARNING! Only purely resistive loads may be connected. Connecting an
incorrect load (e.g. fan heater) will lead to destruction of the load.
WARNING! No electronic thermostats may be used in the loads. The use of
electronic thermostats will lead to destruction of the Ohmpilot and/or the load.
Mechanical temperature switches must be used.
IMPORTANT! In hard water areas, calcification of the heating element may occur, par-
ticularly if the target temperatures are set to over 60 °C. We recommend a yearly inspec-
tion. To execute this, dismantle the heating element from the storage tank and remove
the limescale. Do not scratch the surface of the heating element (formation of corrosion).
Phase 2 Phase 3
- -
3 kW fixed -
3 kW fixed 3 kW fixed
