Choice Of Location - General Remarks - Fronius Ohmpilot Bedienungsanleitung

Choice of The following criteria should be taken into account when choosing a location for the
Location - Ohmpilot:
General Remarks
Install only on a solid surface.
If the Ohmpilot is installed in an enclosed space, then forced-air ventilation must be pro-
vided to ensure adequate heat dissipation.
IMPORTANT! The maximum cable length from the output of the Ohmpilot to the load
(heating element) must not exceed 5 m.
58
Do not install the Ohmpilot such that it overhangs with its connection
sockets facing upwards.
Do not install the Ohmpilot such that it overhangs with its connection
sockets facing downwards.
Do not install the Ohmpilot on the ceiling.
Max. ambient temperatures:
0 °C / +40 °C
Relative humidity:
0 - 99%
The direction of air flow within the
Ohmpilot is from the bottom to the top
