EN - ENGLISH
Set up the Pole Clamp
The Irrigator can be affixed to a .6'' to 1 .5'' (15 mm-38 mm) diameter IV pole using the optional Pole Clamp .
1. Follow the instructions to install the Bracket to the Irrigator (see Steps 1-5 above), if not already completed .
2. Open the Pole Clamp by turning the knob counterclockwise .
3. Position the Pole Clamp around the IV pole and turn the knob clockwise to tighten .
4. Locate the locking pin hole on the front Bracket flange (see Figure 2) to ensure alignment with the locking pin
on the plate (see next step) .
5. Slide the Bracket flanges into the mounting plate of the Pole Clamp up to the spring-loaded locking pin (see
Figure 6) on the plate .
6. Pull down on the locking pin and continue to slide the Bracket into place until it aligns with the locking pin
hole .
7. Release the locking pin to secure the Bracket into the mounting plate .
Spring-loaded
locking pin
Figure 6: Bracket Mounted to IV pole (shown without mounted Irrigator for detail)
Irrigator Mounted on Floor Stand
Tension adjustment
screws
