5. SAFETY INFORMATION

Understand the operation of all controls and learn how to stop the
engine quickly in case of emergency. Make sure the operator
receives adequate instruction before operating the equipment.
• Your engine's exhaust contains poisonous carbon monoxide.
Do not run the engine without adequate ventilation, and never
run the engine indoors.
• The engine and exhaust become very hot during operation. Keep
the engine at least 1 meter (3 feet) away from buildings and other
equipment during operation. Keep flammable materials away
and do not place anything on the engine while it is running.
6. COMPONENT IDENTIFICATION AND SAFETY
INFORMATION
RECOIL
STARTER
GRIP
FUEL TANK CAP
AIR
CLEANER
OIL FILLER
CAP/DIPSTICK
SPARK PLUG
MUFFLER
CAP
GXV140
READ OWNER'S MANUAL BEFORE OPERATION
LIRE LE MANUEL D'UTILISATEUR AVANT USAGE
VOR INBETRIEBNAHME UNBEDINGT BEDIEMUNGSANLEITUNG DURCHLESEN
NO UTILIZAR SIN ANTES NO HABER LEIDO EL MANUAL
HONDA POWER EQUIPMENT MFG INC
RECOIL
STARTER GRIP
FUEL TANK CAP
AIR
CLEANER
OIL FILLER
CAP/DIPSTICK
SPARK PLUG
CAP
MUFFLER
GXV160K1
5

7. THROTTLE CABLE CONNECTION

The throttle lever is provided with hole for attaching the throttle
cable.
1.Remove the screw (1) and the
cable holder (2).
2.Hook the cable end into the
throttle lever, as shown (3).
3.Move the throttle cable control
into the fast (or high) throttle
position.
4.Move the throttle lever by pulling
the throttle cable until the throttle
lever (4) just contacts the choke
arm (5). Install the cable holder
securing the throttle cable and
tighten it securely.
5.Move the throttle control to the
choke position and verify that the
engine choke rod (6) moves the
carburetor choke arm fully closed.
If necessary, adjust screw (7) so it
just contacts the choke arm.
(6)
(3)
(5)
(7)
(1)
GXV140
(6)
(3)
(5)
(7)
(4)
GXV160K1
6
(2)
(4)
(2)
(1)
