probst EASYFILL EF-H Betriebsanleitung Seite 67

®
The RUFLEX torque limiter is delivered in assembled condition.
Components RUFLEX
Component Quantity
1 1
2 1
3 1
4 6*
5 see table 3 disk spring
* with size 00 quantity = 3
Table 1:
®
RUFLEX size
Number of disk spring adjusting screws
Number of disks
number of spring rings
t o r q u e l i m i t e r
m o u n t i n g i n s t r u c t i o n s
®
torque limiter size 00 - 5
Designation
hub
pressure ring
setting nut
torque adjusting screws
picture 1: RUFLEX
®
R U F L E X
Component Quantity
6 2
7 1
8 1
9 1
10 1
®
size 00 - 5
6
8 12
8 12
8 12
KTR-N 46010 E
sheet: 2
edition: 3
Designation
friction lining
slide bush
set screw
safety disk
driving component (e. g. sprocket)
7
16
16
16
8
