General hints of assembly
• Please make sure that the RUFLEX
• Clean the sliding surfaces of the hub, the driving component, the pressure disk and the friction
linings concerning dirt, oil and grease.
• Protect the torque limiter against any axial displacement on the shaft by a grub screw DIN 916 with
toothed cup point or end disk.
C A U T I O N !
!
Dirty sliding surfaces affect the function of the torque limiter.
Centering slide bush
• Check the width of the centering slide bush.
ZenBu = 1,5 x s + b
1 1
e. g.:
®
RUFLEX torque limiter size 1
Width of driving component e. g. b
Width of friction lining s
1,5 x 3 + 8 = 12,5 mm
ZenBu = If you do not indicate the width of the driving
component when placing your order, the centering
slide bush is delivered in max. length.
C A U T I O N !
!
If you do not observe the stipulated width of the centering slide bush, the function
of the torque limiter is not guaranteed.
Table 2:
®
RUFLEX size
max. width of the
centering slide bush
Disk spring layer
single layer (standard)
1TF
size 0 - 5
t o r q u e l i m i t e r
m o u n t i n g i n s t r u c t i o n s
®
torque limiter is in a technically excellent condition.
= 8 mm
1
= 3 mm
1
00 0 01
4,2 10 13
®
R U F L E X
1 2 3
15 17 21,5 24,5
KTR-N 46010 E
sheet: 3
edition: 3
picture 3: centering slide bush
4 5 6
28 31
7 8
33 33
