Mehrsparten-Bauherrenpaket
MSH Basic FUBO SR4 BHP
Beschädigung durch unsachgemäße Lagerung!
Bei unsachgemäßer Lagerung können Sachschäden in erheblicher Höhe ent-
stehen.
• Mehrsparten-Bauherrenpaket vor der Montage vor Beschädigungen, Feuchte
und Verunreinigungen schützen. Es dürfen nur unbeschädigte Teile montiert
werden.
• Die Lagerung des Mehrsparten-Bauherrenpaketes muss so erfolgen, dass dieser
keinen zu niederen Temperaturen (<5 °C) und höheren Temperaturen (>30 °C)
sowie keiner direkten Sonneneinstrahlung ausgesetzt ist.
Entsorgung
Sofern keine Rücknahme- oder Entsorgungsvereinbarung getroffen wurde, zer-
legte Bestandteile nach sachgerechter Demontage der Wiederverwertung zufüh-
ren:
• Metallische Materialreste nach den geltenden Umweltvorschriften verschrotten.
• Elastomere nach den geltenden Umweltvorschriften entsorgen.
• Kunststoffe nach den geltenden Umweltvorschriften entsorgen.
• Verpackungsmaterial nach den geltenden Umweltvorschriften entsorgen.
EN Safety Instructions and Information
Target Group
The installation may only be carried out by technical experts.
Qualified and trained individuals carrying out installation must have
• knowledge of general safety and accident prevention regulations as amended,
• knowledge of how to use safety equipment,
• knowledge of how to use hand tools and electric tools,
• knowledge of the relevant standards and guidelines for laying pipes/cables and
for backfilling utility trenches as amended,
• knowledge of the regulations and installation guidelines of the supply company
as amended,
• knowledge of the waterproof concrete directive and building waterproofing
standards as amended.
General information and intended use
In line with their intended use, our products have been developed solely for instal-
lation in buildings made of state-of-the-art materials. Insofar as no express written
confirmation has been provided by us, we do not accept any liability for any other
purposes or purposes going beyond the above.
For warranty conditions, please see our current General Terms and Delivery Condi-
tions. We explicitly draw your attention to the fact that no warranty whatsoever
applies for any subsequent damage occurring as a result of failure to follow the
installation instructions or if our products are used incorrectly or combined with
third-party products.
The building package MSH Basic FUBO SR4 BHP for the collective feeding in and
sealing of all supply lines (power, water, telecommunications, gas) for buildings
without a basement and for holding the seal insert MSH Basic MBK R4 is suitable
for use in all common gas building entry combinations.
Safety
This section provides an overview of all the main safety aspects for optimum pro-
tection of personnel and a safe installation process.
If there is a failure to observe the instructions and safety information set out here,
this may result in significant hazards.
When installing the seal insert MSH PolySafe MBK, it is imperative to observe the
relevant professional association rules, the VDE provisions, the relevant national
safety and accident prevention regulations and your company's guidelines (work
and procedure instructions).
The fitter must wear the relevant protective clothing.
Only intact components may be installed.
Prior to installation of the Multi-line building package MSH
Basic FUBO SR4 BHP, the following instructions must be ob-
served:
WARNING!
Risk of injury in the event of improper installation!
Improper installation can result in significant bodily harm and property da-
mage.
• Observe the nationally applicable laying and filling regulations for pipes and
cables.
• Seal the underground and cable substructure well prior to laying pipes or cables
so that the latter cannot subside.
NOTICE!
No sealing due to incorrect installation!
Improper installation can result in damage.
• Incorrect cable/duct installation and improper filling of the cable trench results
in subsidence and can therefore potentially cause damage and leaks.
Art. Nr.: 3030476041 Rev.: 00/2022-10-26
• The relevant country-specific standards and regulations shall be observed when
carrying out concreting work. This applies in particular to concrete structural
components impermeable to water in accordance with EN206-1.
• Arrangement must be parallel to the wall.
• The flange of the basic unit corresponds precisely to the minimum clearance to
the wall inside surface (finished, plastered wall) of 5 cm.
• In the case of extremely thin floor slabs, a sufficient concrete thickness (>
15 cm) must be ensured in the area of the multi-line building entry (circum-
ferential > 5 cm).
• The position of the MSH Basic FUBO SR4 BHP must be agreed upon with the
energy suppliers!
• The basic unit must not be covered by the inner walls later (shell wall + plaster).
• When positioning the Multi-line building package MSH Basic FUBO SR4 BHP,
care must be taken to ensure that the installation fixture does not hinder the
empty conduit route (spiral hose).
• The connection to the interior installation may not exert any force on the gas
building entry.
• If no gas fitting is to be installed for the time being, a blind sealing element
must be fitted.
• The current building waterproofing standard DIN 18533 for underground struc-
tural components is to be observed.
• The application of the component in conjunction with pre-applied fully-bonded
membrane (FBM) is not covered by DIN 18533. Suitable installation always de-
pends on the sealing sheet system manufacturer and local circumstances, and
only possible after consultation.
• No cleaning agents containing solvent may be used for cleaning the Multi-line
building package. We recommend using the KRMTX cable cleaner.
• For details of other accessories and further information, see www.hauff-tech-
nik.de and the technical data sheets as well as the safety data sheet.
Personnel requirements
Qualifications
WARNING!
Risk of injury in case of inadequate qualification!
Improper handling can result in significant bodily harm and property da-
mage.
• Installation may only be carried out by qualified and trained individuals who
have read and understood these instructions.
Skilled experts
Based on their specialist training, skills, experience and familiarity with the rele-
vant provisions, standards and regulations, skilled experts are able to carry out the
work assigned, independently identifying and avoiding potential hazards.
Transport, packaging, scope of delivery and storage
Safety instructions in connection with transport
NOTICE!
Damage in the event of improper transport!
Significant damage can occur in the event of improper transport.
• When unloading packaging items on delivery and in the course of in-house
transport, proceed with care and observe the symbols on the packaging.
Transport inspection
Inspect the delivery immediately on receipt for completeness and transport da-
mage. In the event of transport damage being visible from the outside, proceed as
follows:
• Do not accept the delivery or only do so subject to reservations.
• Make a note of the extent of damage in the transport documentation or de-
livery note provided by the transporter.
• Submit a claim for every defect as soon as it has been identified.
• Claims for damages can only be asserted within the applicable claim
period.
Scope of supply
The scope of delivery of the Multi-line building package MSH Basic FUBO SR4 BHP
includes:
• Basic unit including height-adjustable installation fixtures with mounted water
barrier flange
• 4 Hateflex14078 MRD spiral hoses with adaptation pipe incl. mounted 3-ribbed
seals
• 1 seal insert without gas entry combination
• 1 utility sealing element, water SDW 1x32/40/50
• 1 utility sealing element, electricity SDE 1x26-29/36-39/43-46/48-51
• 1 utility sealing element, communications SDK 1x13-21+3x7-13+1x5-13
• 1 gas assembly kit, Schuck+RMA incl. blind plug MBHP DN25 D0
• 2 sleeve caps MS78U 1x24-52 for electricity and water
• 1 sleeve cap MS78K 1x13-21+3x7-13+1x5-12 for communications
