Multi-line building package
MSH Basic FUBO SR4 BHP
2
ENMulti- lin e building pac kag e
Table of Contents
1
Publishing Notes ...................................................... 18
2
Explanation of Symbols ........................................... 18
3
Tools and aids required ........................................... 18
4
Description .............................................................. 18
5
unit) ........................................................................ 19
6
Preparing for installation ......................................... 19
7
Installing the basic unit ............................................ 19
8
Applying seal to the basic unit flange ...................... 23
9
Installing the sleeve caps ......................................... 23
9.1
electricity/water .................................................... 23
9.2
for communication ............................................... 24
9.3
MS78 D0 - Sleeve caps for blind sealing ............... 24
9.4
Assembly at pipe ends .......................................... 25
10 Description of the seal insert ................................... 26
11 Installing the seal insert ........................................... 26
12 Installing the extension set ...................................... 29
1 Publishing Notes
Copyright © 2022 by
Hauff-Technik GmbH & Co. KG
Department: Technical Editing
Robert-Bosch-Straße 9
89568 Hermaringen, GERMANY
Tel.
+49 7322 1333-0
Fax
+49 7322 1333-999
E-mail
office@hauff-technik.de
Internet
www.hauff-technik.de
Reproduction of this Installation instructions - even in
extracts - in the form of reprint, photocopy, on electronic
data media or using any other method requires our writ-
ten consent.
All rights reserved.
Subject to technical alterations at any time and without
prior announcement.
These installation instructions form part of the product.
Printed in the Federal Republic of Germany.
2 Explanation of Symbols
1
Work stages
► Effect/result of a work step
Reference numerals in drawings
18
3 Tools and aids required
The following tools, aids and accessories are required in
addition to the standard tools to ensure proper installation
of the Multi-line building package MSH Basic FUBO SR4
BHP:
Tools:
1/4 inch torque wrench + socket or tool kit
MSH/ESH (Art. No.: 5200010301)
6 mm internal hex (e.g. Hauff MSH MWKZ tool set)
GMT lubricant (Art. No.: 2790009100)
4 Description
Description: MSH Basic FUBO SR4 BHP
1
Seal insert
2
Basic unit with flange and compensation frame
3
3-ribbed seal (adjustable)
4
Spiral hose with adapter pipe
5
Water barrier flange
6
Installation fixture, height-adjustable
7
Wing screw
8
Ground spike
Art. Nr.: 3030476041 Rev.: 00/2022-10-26
EN
