Dimensions

Diagram 5: Xgard aluminium and stainless steel dimensioned view

155.5 mm
10
36 mm
M6 / ¼"
146 mm
166.3 mm
Height 111 mm
Hauteur 111 mm
Höhe 111 mm
Altura 111 mm
Hoogte 111 mm
Polish height 111 mm
Altura 111 mm
Xgard and Xgard IR
M20,
½" / ¾" NPT
M6 / ¼"
